User's manual
Following are the function buttons of the IFMEXT module; access and activation of these depend on the access level of
the user.
• Disable/Enable extinguishment: button to disable/enable an ongoing fire extinguishment procedure.
• Disable/Enable automatic extinguishment: button to disable/enable automatic activation of fire extinguishment
commands.
• Disable/Enable manual extinguishment: button to disable/enable manual activation of fire extinguishment
commands.
3.10

Extinguishment module LED panel (FPMEXT)

If the control panel is set up to manage fire extinguishing systems, one or more modules (external FPMEXT modules) will
be installed on the front plate of the control panel cabinet.
Each module has 40 tricolour LEDs which replicate the signals of up to 5 IFMEXT.extinguishment modules on the control
panel front plate.
FPMEXT LED
Extinguishment
channel activation LED
Extinguishment channel
disabled LED
Automatic activation
Manual activation LED
Manually locked
extinguishment LED
Lock extinguishment
command LED (lock
command from non-
electrical-device)
Generic fault LED
CPU fault LED
User interface
Colour
Red
Yellow
Red
LED
Red
Yellow
Yellow
Yellow
Yellow
On solid
Discharge activated
Channel disabled
Automatic discharge
command activated
Manual discharge command
activated
Extinguishment locked
Extinguishment locked
/
Generic CPU fault on
extinguishment module
Flashing
Pre-extinguishment condition
running
/
Automatic discharge
command partially activated
/
Fault on lock-extinguishment
circuit
Fault on lock-extinguishment
circuit
Generic fault on
extinguishment channel
/
19
