2.1 Checking components

2.1.1 Checking the Contents

[1]
[2]
[3]
Caution
1. You will need the ferrite core and tie-wrap if you will be connecting a USB cable for
connection of a USB device. (outside North America only)
2. If the site of installation is in the US, you will not need the ferrite core or tie-wrap.
F-2-1
T-2-1
USB Application Interface Board-D1
Ferrite core
Tie-wrap
Chapter 2
0007-7638
1 pc.
2 pc.
2 pc.
2-1
