2.1 Unpacking and Checking the Components

2.1.1 Points to Note About Installation

The machine calls for the separately available power
supply Unit-S1. (Only for imagePRESS C1 series)

2.1.2 Checking the Contents (DADF-R1)

[1]
[4]
[9] [10]
[1] DADF
[3] Fan unit
[5] Fan duct
[7] Electrostatic filter
[9] Screw (P tight; M4X10)
[11] Harness retainer
[13] Manual Feeder Placement label
*: Included only for UL.
[5]
[11]
F-2-1
1 pc. [2]
1 pc. [4]
2 pc. [6]
2 pc. [8]
6 pc. [10]
2 pc. [12]
1 pc. [14]*
[2]
[6]
[12] [13]
Original delivery tray
Fan holder
Cover duct
Screw (Bind; M4X30)
Screw (RS tight; M4X10)
Cleaning instruction label
(only with the products designed for USA/EUR)
(only with the products designed for AUS/ASIA)
Sheet, FCC Class A
Chapter 2
[3]
[7] [8]
[14]
1 pc.
2 pc.
1 pc.
4 pc.
2 pc.
4 pc.
5 pc.
1 pc.
0014-6095
14-2693
2-1
