Welch Allyn Connex
Quick Reference Card
Office profile
Manually enter patient information
1. From the Home tab, touch the keyboard icon in the Patient frame.
2. Enter patient information.
3. Touch OK.
4. To change the patient type, touch the patient type button
(located on the right side of the Patient frame).
Enter weight and height
From the Home tab, touch the up/down arrow keys or the
keypad to manually adjust weight and height.
Note If an approved, battery-powered weight scale
is attached to the monitor, weight and height
measurements from the weight scale populate
fields in the BMI frame.
The BMI value changes based on weight and height input.
Start/Stop blood pressure
Office Profile
®
Enter pain level
From the Home tab, touch the up/down arrow keys
or the keypad to manually adjust the pain level.
Clear patient data
Touch Clear to delete all measurements from the
Home tab without saving them.
Save patient data
After taking patient measurements, touch Save.
Battery status
Charging
Approximate operating time remaining
Battery removed or not holding a charge
Power on/Standby
• Powers up the monitor
• Brief press – Sets monitor to
Display power saving mode
