- Page 1 ANI-42HPIP 4K@60Hz UHD+ 4x2 HDMI Seamless Switching Multiviewer A-NeuVideo.com Frisco, Texas 75036 AUDIO / VIDEO MANUFACTURER...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
-
Page 3: Table Of Contents
INTRODUCTION DISCLAIMERS The ANI-42HPIP 4x2 Multiviewer is a high performance HDMI The information in this manual has been carefully checked and switch with integrated scaling and multi-windowing technology. It is believed to be accurate. We assume no responsibility for any... -
Page 4: Features / Applications / System Requirements
NEUVIDEO FEATURES FEATURES • HDMI inputs and outputs with 18Gbps (600MHz) 4K UHD support • DVI 1.0 compatible with the use of an HDMI-DVI adaptor • HDCP 1.x and 2.2 compliant • Supports HD resolutions up to 4K@60Hz (4:4:4, 8-bit) •... -
Page 5: Specifications
NEUVIDEO SPECIFICATIONS Specifications • HDMI Bandwidth: 600MHz/18Gbps • Input Ports: (4) HDMI • Output Ports: • (2) HDMI • Balanced Stereo (5-pin Terminal Block) • Control Interfaces: • RS-232 (5-pin Terminal Block) • IP Control (RJ-45) • Power Supply: 12V/3A DC (US/EU standards, CE/FCC/UL certified) •... -
Page 6: Operation Controls & Functions
NEUVIDEO Operation controls & Functions Front Panel POWER: Press this button to power the unit on (green LED) or place it into stand-by mode (red LED). IR WINDOW: Accepts IR signals from the included IR remote for control of this unit only. MATRIX A/B IN1~IN4: These input selection buttons behave differently depending on the current input and output resolutions in use. -
Page 7: Rear Panel
NEUVIDEO Operation controls & Functions BACK Panel HDMI IN 1~4: Connect to HDMI source equipment such as media players, game consoles or set-top boxes. DVI source equipment may be connected by using an HDMI to DVI adapter. HDMI OUT A~B: Connect to HDMI TVs, monitors or amplifiers for digital video and audio output. -
Page 8: Remote Control
NEUVIDEO Remote Control Remote Control POWER: Power on the machine or enter to standby mode. INFO: Display the current status/ information of the unit. A1~A4 & B1~B4: (Matrix Selection) A. WHEN ALL INPUTS AND OUTPUTS ARE BELOW 4K: Press any of these buttons to seamlessly switch to the selected input (1~4) for display on the associated output (A or B). -
Page 9: Rs-232 Control / Telnet Control
NEUVIDEO RS-232 CONTROL / Telnet Control RS-232 CONTROL SERIAL PORT SETTINGS: MATRIX TERMINAL Baud Rate: 115200bps PINOUT PINOUT Data Bit: 8bits Parity: None Flow Control: None Stop Bit: 1 Telnet Control Before attempting to use Telnet control, please ensure that both the unit and the PC are connected to the same active networks. TO ACCESS THE COMMAND LINE INTERFACE (CLI) Windows 7 Click START, type “cmd”... -
Page 10: Rs-232 / Telnet Commands
NEUVIDEO RS-232 & Telnet Commands RS-232 & Telnet Commands BASIC COMMANDS COMMAND DESCRIPTION VARIABLES HELP 8 Show the full command list. Show the full command list. Show the current firmware version. GET FW VER 8 GET MODEL NAME 8 Show the model name. GET MODEL TYPE 8 Show the model type. - Page 11 NEUVIDEO RS-232 & Telnet Commands VIDEO COMMANDS CONT’D COMMAND DESCRIPTION VARIABLES Set the routing source for output N1 and switch to N1 = A~B SET OUT N1 ROUTE N2 8 [Output letter] matrix mode. N2 = 1~4 [Input number] GET OUT N1 ROUTE 8 Show the matrix mode routing source for output N1.
- Page 12 NEUVIDEO RS-232 & Telnet Commands SCALER COMMANDS CONT’D COMMAND DESCRIPTION VARIABLES SET WINDOW N1 LAYOUT Set the aspect ratio to use for window N1 in layout N1 = 1~4 [Window number] MODE N2 ASPECT RATIO mode N2. Available values for N2: N3 8 [3+1 quad view] [Side-by-Side]...
- Page 13 NEUVIDEO RS-232 & Telnet Commands OSD COMMANDS COMMAND DESCRIPTION VARIABLES GET OUT A OSD BANNER Show the current state of the OSD info banner DISPLAY 8 display. SET OUT A OSD BANNER Set the position of the OSD info banner. Available values for N1: LOCATION N1 8 [Upper-left]...
- Page 14 NEUVIDEO RS-232 & Telnet Commands EDID MANAGEMENT COMMAND DESCRIPTION VARIABLES Set the EDID to use on Input N1. SET IN N1 EDID N2 8 N1 = 1~4 [Input number] [UHD+/2CH] Available values for N2: [FHD/2CH] [UHD+/MCH] [FHD/MCH] 7~10 [User EDID 1~4] [UHD/2CH] [Sink A] [UHD/MCH]...
-
Page 15: Webgui Control
NEUVIDEO WebGUI Control WebGUI Control DEVICE DISCOVERY: Please obtain the “Device Discovery” software from your authorized dealer and save it in a directory where you can easily find it. Connect the unit and your PC/Laptop to the same active network and execute the “Device Discovery” software. - Page 16 NEUVIDEO WebGUI Control WebGUI Control INPUT: This tab displays the current status of each of the (4) inputs, allows renaming each input, and provides a way to set the unit’s HDCP handling behavior. 1. Video Timing: Shows the currently detected resolution and timing of each video input.
- Page 17 NEUVIDEO WebGUI Control WebGUI Control 4. OSD Information: This section provides control over the OSD Information display for each window. When the OSD switch is set to “ON”, each window will display (2) lines of input information including the input’s name and detected resolution. The position of the OSD Information is controlled by changing the “OSD Location”...
- Page 18 NEUVIDEO WebGUI Control WebGUI Control 1. Quad View: Quad View displays (4) equally sized windows. Each window has an independently selected source. Audio always follows the source selected in the Audio tab. NOTE: See “Features Support Chart” on Pg. 2 for supported Input/Output resolutions.
- Page 19 NEUVIDEO WebGUI Control WebGUI Control • PiP Position: There are (2) ways to change the position of the PiP window. Clicking on the PiP window and dragging it will move the window freely. To position the PiP window with more accuracy, move the X Position and Y Position sliders. The X and Y coordinates correspond to the position of the upper left corner of the PiP window and cannot exceed the horizontal (X) or vertical (Y) size of the currently selected output resolution.
- Page 20 NEUVIDEO WebGUI Control WebGUI Control 2. Sink EDID Download: To save the EDID from one of the connected displays to your local PC, select the appropriate sink from the dropdown list then press the “Download” button. Depending on your browser settings you will either be asked where to save the downloaded file, or the file will be transferred to the default download location on your PC.
- Page 21 NEUVIDEO WebGUI Control WebGUI Control When in DHCP mode, the unit will attempt to connect to a local DHCP server and obtain IP, netmask and gateway addresses automatically. Please press “Save” after making any changes to the IP configuration or mode. NOTE: The unit’s default IP address is 192.168.1.50.
-
Page 22: Connection Diagram
NEUVIDEO CONNECTION DIAGRAM CONNECTION DIAGRAM... -
Page 23: Video Specifications
NEUVIDEO Video Specifications Resolution Support Tables PC RESOLUTIONS INPUT (HZ) OUTPUT (HZ) 640x480 60, 72, 75, 85 800x600 56, 60, 72, 75, 85 1024x768 60, 70, 75, 85 1028x768 60, 75 1280x800 60 (RB), 60 1280x960 1280x1024 1360x768 1366x768 1400x1050 60 (RB), 60 1440x900 60 (RB), 60... - Page 24 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
