A-Neuvideo ANI-2PIPU-LOGO Instruction Manual

2x1 hdmi pip/pop scaler dynamic multiviewer 4k@30hz w/ logo inserter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ANI-2PIPU-LOGO
2x1 HDMI PiP/PoP Scaler Dynamic Multiviewer 4K@30Hz w/ LOGO Inserter
PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the box:
• ANI-2PIPU-LOGO 2x1 UHD 4K HDMI Multi-Window Scaler Switcher
• 24V/2.7A DC Power Adapter
• (2) 3-pin Terminal Block
• 3.5mm to IR Extender Cable
• 3.5mm to IR Blaster Cable
A-NeuVideo.com
Frisco, Texas 75036

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANI-2PIPU-LOGO and is the answer not in the manual?

Questions and answers

Related Manuals for A-Neuvideo ANI-2PIPU-LOGO

Summary of Contents for A-Neuvideo ANI-2PIPU-LOGO

  • Page 1 Before attempting to use this unit, please check the packaging and make sure the following items are contained in the box: • ANI-2PIPU-LOGO 2x1 UHD 4K HDMI Multi-Window Scaler Switcher • 24V/2.7A DC Power Adapter • (2) 3-pin Terminal Block •...
  • Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.

  • Page 3: Table Of Contents

    NEUVIDEO TABLE OF CONTENTS CONTENTS INTRODUCTION ................1 SAFETY PRECAUTIONS FEATURES SYSTEM REQUIREMENTS.........2 Please read all instructions before attempting to unpack, install or SPECIFICATIONS ................3 operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this OPERATION CONTROLS &...

  • Page 4: Features / System Requirements

    NEUVIDEO FEATURES / SYSTEM REQUIREMENTS / APPLICATIONS FEATURES • HDMI 2.0 and DVI 1.0 compliant • HDCP 1.x and 2.2 compliant • (2) HDMI inputs, (2) mirrored video outputs (HDMI & HDBaseT™) • Standard support for up to 4K UHD (10.2Gbps, 4K@30Hz 4:4:4, 8-bit) digital video input (HDMI) and output (HDMI/HDBaseT™) Note: Interlaced resolutions are not supported •...

  • Page 5: Specifications

    NEUVIDEO SPECIFICATIONS SPECIFICATIONS • HDMI Bandwidth: 10.2Gbps • HDBaseT™ Bandwidth: 10.2Gbps • Input Ports: (2) HDMI (Type-A) • Output Ports: • HDMI (Type-A) • HDBaseT™ (RJ-45) • Pass-through Ports: • IR Extender (3.5mm) • IR Blaster (3.5mm) • RS-232 (3-pin Terminal Block) •...

  • Page 6: Operation Controls & Functions

    NEUVIDEO OPERATION CONTROLS & FUNCTIONS FRONT PANEL POWER LED: This LED will illuminate to indicate the unit is on and receiving power. SERVICE PORT: This port is used for User Logo and EDID uploads, and firmware updates. WINDOW 1~2/IN 1~2 LEDs: The illuminated LEDs indicate which source is currently selected for each window.
  • Page 7 NEUVIDEO OPERATION CONTROLS & FUNCTIONS REAR PANEL HDMI IN 1~2 PORTS: Connect to HDMI source equipment such as media players, game consoles, or set-top boxes. RS-232 3-PIN TERMINAL BLOCK: Connect directly to a PC, laptop, or other serial control device with a 3-pin adapter cable to send RS-232 commands to control the unit.

  • Page 8: Ir Cable Pinout / Rs-232 Pinout & Defaults

    NEUVIDEO IR Cable Pinouts / RS-232 Pinout IR Cable Pinouts RS-232 Pinout and Defaults SERIAL PORT DEFAULT SETTINGS Baud Rate: 19200 Data Bits: 8 Parity Bits: None Stop Bits: 1 Flow Control: None...

  • Page 9: Osd Menu

    NEUVIDEO OSD MENU OSD Menu All functions of this unit can be controlled by using the OSD (On Screen Display) which is activated by pressing the MENU button on the front of the unit. Use the + (PLUS), − (MINUS), and ENTER buttons to navigate the OSD menu. Press the MENU button to back out from any menu item and then press it again to close the menu.
  • Page 10 NEUVIDEO OSD MENU OSD Menu The individual functions of the OSD will be introduced in the following section. Items marked in BOLD are the factory default settings. VIDEO MODE 2ND LEVEL 3RD LEVEL Video Mode SWITCHER Custom Window Source IN 1 In 2 Window 1 Source IN 1...
  • Page 11 NEUVIDEO OSD MENU OSD Menu WINDOW LAYOUT 2ND LEVEL 3RD LEVEL 4TH LEVEL Position 1~{Res. max} (1280) 1~{Res. max} (720) Size 1~{Res. max} (639) 1~{Res. max} (359) Aspect Full 16:10 16:9 64:27 KEEP RATIO {Situational} (1.778) Custom Mirror Horizontal Vertical Hori+Vert Transparency 0~15 (0)
  • Page 12 NEUVIDEO OSD MENU OSD Menu WINDOW LAYOUT 2ND LEVEL 3RD LEVEL 4TH LEVEL Border Size 1~20 (10) Border Trans. 0~14 (0) WINDOW 1: 1. POSITION X/Y: Set the horizontal and vertical position of the upper left corner of the window. Opens a special positioning menu allowing adjustments in real time.
  • Page 13 NEUVIDEO OSD MENU OSD Menu COLOR KEY 2ND LEVEL 3RD LEVEL 4TH LEVEL Key On/Off Cursor 0~{Res. max} (0) 0~{Res. max} (0) Color Y 0~255 (168) 0~255 (45) Color Cb Color Cr 0~255 (32) Range Y 0~{Color Y} (32) Range Cb 0~{Color Cb} (32) Range Cr 0~{Color Cr} (32)
  • Page 14 NEUVIDEO OSD MENU OSD Menu PICTURE 2ND LEVEL 3RD LEVEL Contrast 0~100 (50) Brightness 0~100 (50) 0~100 (50) Saturation 0~100 (50) Sharpness 0~10 (0) 0~100 (50) Green 0~100 (50) Blue 0~100 (50) Reset Enter Preset STANDARD Vivid Soft 1. CONTRAST: Set the overall contrast of the output video.
  • Page 15 NEUVIDEO OSD MENU OSD Menu INPUT EDID 2ND LEVEL 3RD LEVEL EDID Mode Independent All EDID FHD/2CH FHD/MCh 4K UHD/2Ch 4K UHD/MCh Sink HDBT Sink HDMI User 1 User 2 User 3 User 4 IN 1 EDID [Same as All EDID] IN 2 EDID [Same as All EDID] User 1 Update...
  • Page 16 NEUVIDEO OSD MENU OSD Menu HDCP MODE 2ND LEVEL 3RD LEVEL Input 1 HDCP Support Off Refer to Source REFER TO DISPLAY Input 2 HDCP Support Off Refer to Source REFER TO DISPLAY 1. INPUT 1/2: Select the HDCP behavior for each input. •...
  • Page 17 NEUVIDEO OSD MENU OSD Menu OSD SETTINGS 2ND LEVEL 3RD LEVEL Menu Position TOP LEFT Top Right Bottom Right Bottom Left Center 0~10 (5) Menu Offset Menu Timeout 5~60 (8) Info.Timeout 5~60 (5) Info.Display Info.Brief Info.NoSignal Transparency 0~15 (2) Text BLUE White Background...
  • Page 18 NEUVIDEO OSD MENU OSD Menu 8. TRANSPARENCY: Set the transparency level of the background of all OSD elements with a range from 0 (opaque) to 15 (fully transparent). 9. TEXT: Set the OSD text color as either blue or white. 10.
  • Page 19 NEUVIDEO OSD MENU OSD Menu ETHERNET 2ND LEVEL 3RD LEVEL IP Mode STATIC DHCP STATIC IP CONFIG IP Address 192.168.1.50 Subnet Mask 255.255.255.0 192.168.1.254 Gateway LINK STATUS IP Mode IP Address Subnet Mask [Current network details] Gateway MAC Addr. 1. IP MODE: Set the unit’s IP address mode to Static or DHCP.
  • Page 20 NEUVIDEO OSD MENU OSD Menu ADVANCED 2ND LEVEL 3RD LEVEL Test Pattern H Ramp V Ramp Diagonal Green Blue Preset Save Preset 1~5 Preset Recall Preset 1~5 Preset Rename Preset 1~5 1. USER SOURCE TIMING: Enable or disable allowing the detection of non-standard input resolutions. 2.
  • Page 21 NEUVIDEO OSD MENU OSD Menu SETUP 2ND LEVEL 3RD LEVEL Auto Sync Off 3 min. 5 min. 10 min. Firmware Update Flash Update HDBT TX FW Update HDBT RX FW Update User EDID Reset Factory Reset 1. AUTO SYNC OFF: Set the amount of time to continue outputting sync with a black screen if there are no live sources and no operations have been executed on the unit.
  • Page 22 NEUVIDEO OSD MENU OSD Menu SETUP 2ND LEVEL 3RD LEVEL Auto Sync Off 3 min. 5 min. 10 min. Firmware Update Flash Update HDBT TX FW Update HDBT RX FW Update User EDID Reset Factory Reset 1. AUTO SYNC OFF: Set the amount of time to continue outputting sync with a black screen if there are no live sources and no operations have been executed on the unit.
  • Page 23 NEUVIDEO OSD MENU OSD Menu INFORMATION 2ND LEVEL 3RD LEVEL SOURCE 1 Resolution Format [Current source details] HDCP Audio SOURCE 2 Resolution Format [Current source details] HDCP Audio HDBT DISP HDCP Port EDID Format Native 1 [Current display details] Native 2 Model HDMI DISP HDCP Port...

  • Page 24: Webgui Control

    WEBGUI CONTROL Device Discovery Please obtain the “Device Discovery” software from our website on the ANI-2PIPU-LOGO page and save it in a directory where you can easily find it. Connect the unit and your PC/Laptop to the same active network and execute the “Device Discovery” software. Click on “Find Devices on Network”...
  • Page 25 NEUVIDEO WEBGUI CONTROL Video Mode Tab This tab provides access to controls for selecting between the Switcher and PiP/PoP output modes of the unit as well as selecting the video source(s) to display and how switching transitions are handled. Note: Both outputs of the unit are linked and will always show the same video contents.
  • Page 26 NEUVIDEO WEBGUI CONTROL Video Mode Tab This tab provides controls over the size, position and other settings for both video windows. Individual features and functions will be enabled or disabled depending on the unit’s current Video Mode setting. Note: In Switcher mode, only window 1’s controls are available.
  • Page 27 NEUVIDEO WEBGUI CONTROL Color Key Tab This tab provides control over the chroma key functions of the unit. Keying values and ranges are set using the full YCbCr color space (0~255). Note: Only available in the PiP and Custom video modes. 1.
  • Page 28 NEUVIDEO WEBGUI CONTROL Audio Tab This tab provides control over the audio output behavior of the unit, including routing selection and muting. 1. SOURCE: Use the dropdown to choose the audio source to pair with the video output. • IN 1: Always use the audio from Input 1. •...
  • Page 29 NEUVIDEO WEBGUI CONTROL HDCP Mode Tab This tab provides control over the HDCP settings for both inputs. 1. HDCP MODE INPUT 1/2: Select the HDCP behavior for each input. • HDCP Support Off: Completely disables support for HDCP on that input. •...
  • Page 30 NEUVIDEO WEBGUI CONTROL 7. INFO. NO SIGNAL: Enable or disable the informational OSD when there is no live source. 8. TRANSPARENCY: Set the transparency level of the background of all OSD elements with a range from 0 (opaque) to 15 (fully transparent).
  • Page 31 NEUVIDEO WEBGUI CONTROL 2. STATIC IP CONFIG: When the unit is in Static IP mode the IP address, netmask and gateway addresses may be manually set here. Click “Save” to apply and use the newly entered address. 3. LINK STATUS: Displays the unit’s current IP configuration and the unit’s MAC address.
  • Page 32 NEUVIDEO WEBGUI CONTROL 3. WEB LOGIN SETTINGS: WebGUI login settings can be set here. • Username/Password: To change the login username and password, enter the new information in the spaces provided and press “Save”. Note: The default user name and password is “admin”. •...
  • Page 33 NEUVIDEO WEBGUI CONTROL Information Tab This tab shows the currently detected details for both inputs and both outputs as well as listing the status of a few critical system settings and relevant firmware versions.

  • Page 34: Telnet Control / Serial & Telnet Commands

    NEUVIDEO Telnet Control / Serial & Telnet Commands Telnet Control Before attempting to use Telnet control, please ensure that both the unit and the PC are connected to the same active networks. O ACCESS THE COMMAND LINE INTERFACE (CLI) Windows 7 Click START, type “cmd”...
  • Page 35 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS GET WINDOW 2 BORDER SIZE 8 Show the current size of the border around window 2. SET WINDOW N1 HSIZE N2 8 Set the horizontal size of the specified window. N1 = 1~2 [Window number] N2 = 1~{Max res} [Horizontal size]...
  • Page 36 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS GET WINDOW 1 ZOOM 8 Show the current zoom setting of window 1. SET WINDOW 1 CUSTOM ZOOM Set the zoom level of window 1 to use when in Custom mode. N1 8 N1 = 200~2000 [Zoom level in 0.1% units]...
  • Page 37 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS SET WINDOW 2 COLOR CR N1 8 Set the base Cr value for window 2’s chroma key. N1 = 0~255 [Base Cr value] GET WINDOW 2 COLOR CR 8 Show the current base Cr value for window 2’s chroma key. SET WINDOW 2 COLOR RANGE Y Set the Y value range for window 2’s chroma key.
  • Page 38 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS GET AUDIO OUT A MUTE 8 Show the current mute state of the audio output. SET AUDIO OUT A ROUTE N1 8 Output the specified audio source. Available values for N1: [HDMI Input 1] [Window 1] [HDMI Input 2]...
  • Page 39 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS GET OUT A TIMING 8 Show the current output resolution. SET OUT A OSD TIMIEOUT N1 8 Set the OSD Menu’s timeout value (in seconds). Available values for N1: [Timeout disabled] 5~60 [Timeout in seconds] GET OUT A OSD TIMEOUT 8...
  • Page 40 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS GET OUT A OSD INFO NOSIGNAL 8 Show the current setting for the “No Signal” OSD information display. SET OUT A OSD LOGO DISPLAY Enable or disable the graphical logo overlay. N1 8 Available values for N1: [Disabled]...
  • Page 41 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS SET IP MODE N1 8 Set the IP address assignment mode. Available values for N1: STATIC [Static IP mode] DHCP [DHCP mode] GET IP MODE 8 Show the current IP address assignment mode. GET IPCONFIG 8 Show the unit’s current IP configuration information.
  • Page 42 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS SET PATTERN TYPE N1 8 [White field] [Vertical ramp] [Crosshatch] [Diagonal lines] CONT’D [Colorbars] [Red field] [Grayscale] [Green field] [White window] [Blue field] GET PATTERN TYPE 8 Show the currently selected test pattern output mode. SET IN TIMING DETECT N1 8 Enable or disable User Source Timing detection.
  • Page 43 NEUVIDEO SERIAL & TELNET COMMANDS COMMAND DESCRIPTION AND PARAMETERS GET FEEDBACK BROADCAST 8 Show the current command feedback display state. GET COMMAND VER 8 Show the unit’s current command version. GET MAC ADDR 8 Show the unit’s MAC address. GET MODEL NAME 8 Show the unit’s model name.

  • Page 44: Video / Audio Specifications

    NEUVIDEO VIDEO / AUDIO SPECIFICATIONS Video Specifications INPUT OUTPUT INPUT OUTPUT SUPPORTED SUPPORTED RESOLUTIONS (HZ) RESOLUTIONS (HZ) HDMI HDMI HDBT HDMI HDMI HDBT 720x400p@70/85 1600x1200p@60 ü ü ü ü 640x480p@60/72/75/85 1680x1050p@60 ü ü ü ü 720x480i@60 1920x1080i@50/60 720x480p@60 ü ü ü...

  • Page 45: Cable Specifications / Hdbaset™ Features

    NEUVIDEO CABLE SPECIFICATIONS / HDBASET™ FEATURES Cable Specifications Digital Audio 1080p 4K30 4K60 8-bit 12-bit (4:4:4) 8-bit (4:4:4) 8-bit CABLE LENGTH High Speed HDMI Cable HDMI Input 15m 10m 5m 3m 49 ft / 15M 32 ft / 10M 16 ft / 5M 9 ft / 3M HDMI Output 15m 10m 5m 49 ft / 15M...

  • Page 46: Connection Diagram

    NEUVIDEO CONNECTION DIAGRAM CONNECTION DIAGRAM...
  • Page 47 THIS PAGE IS INTENTIONALLY LEFT BLANK.
  • Page 48 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
