Abaxis VetScan SA User Manual page 11

1
4
Input/output panel
Ports
(1) Ethernet
(4) Mouse port
Note: The Ethernet ports have not been enabled yet but will be in a future software update.
The HDMI and DVI ports are not supported and should not be used to connect a display monitor.
2
3
5
Reagent connection panel
(2) USB ports
(5) Keyboard port
RINSE A
RINSE B
SENSOR WASTE
(3) VGA monitor port
V ETS CA N SA U SE R' S M A N UA L 1 .1 S O F TWA RE | 1 1
