iLink RGB Pro
Linkable colour DMX laser effects
M A N U A L
V E R S I O N
1 . 0
0 4 - 0 8 - 2 0 1 6
For safety guidelines and advice, please refer to the Kam Laser Safety Guide available for download
from the Kam website: www.kam.co.uk
Due to continuous product development, please ensure that you have downloaded
the latest instruction manual for this product from the Kam website
For the latest updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc. E&OE.
M
A
D
E
I
N
C
H
I
N
A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for KAM iLink RGB Pro
Summary of Contents for KAM iLink RGB Pro
- Page 1 For the latest updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com...
- Page 2 Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. Please retain them for future reference.This unit has been tested at the factory before being shipped to you.
- Page 3 Front and rear panels Laser aperture This is the opening where laser light will appear from. Power LED Indicates that the unit is switched on Music LED Synchronises to any detected music/sound signal Infrared receiver Remote controller signal receiver DMX Out 3 pin female XLR connector DMX In 3 pin male XLR connector...
- Page 4 Control and function Regular breaks during operation are essential to maximise the life of this device as it is not designed for continual use. Always unplug the unit when it is not being used for long periods or before servicing. In the event of serious operation problems, stop using the unit and contact your dealer immediately.
- Page 5 DMX mode Press the function button (Func) to enter Mode options Press the function button until the LED panel shows 001 Press the Enter button to confirm the setting or change the address using the Up and Down buttons Press the Enter button to confirm the setting The laser will now be working in DMX mode DMX mode / DMX address setting Ensure the unit is in DMX mode (see above)
- Page 6 DMX table Channel Value Function 000-029 Automatic show with original preprogrammed colour 030-059 Auto show with green and yellow 060-089 Auto show with blue and purple 090-119 Auto show with cyan and white Channel 1 - mode 120-149 Sound activated show with original preprogrammed colour 150-179 Sound activated show with green and yellow 180-209...
- Page 7 Pattern list in channel 2 Caution Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Safety warning stickers The yellow and black safety stickers that are attached to the laser unit are warnings that need to be adhered to. This above sticker is placed next the laser aperture on the front of the unit.
-
Page 8: Specification
This sticker is placed on the top/rear of the unit to indicate that if the chassis is opened, exposure to Class 3B laser light can occur. For safe operation of the iLink laser series Please adhere to the distances shown in the diagram below. It is not recommended that the laser is pointed at an area where audience will be present.
