Character Control Board Type 2
Head Turn Motor Wire
(Blue/Yellow)
Mouth Switching Power
(Black/Yellow)
70
Signal From Lower Robot RC Receiver
Mouth Trigger
Purple Jumper/Purple
Character Control Board
(Blue/Black/Orange)
Head Turn
Feedback
12v Power from
Lower Robot
Signal to Eye
Servo Board
Yellow/Grey/Black
5 Volts to
Eye Servo Board
Black/Red
Servo Board-
Eyes and Mouth
