Vehicle Top 2 – Underside View
Eyelid Rod
Servo Arm
Right Eyelid Servo
Right Body Latch
(P.C.
™
)
Eyes L/R Servo
Servo Arm Set Screw
(M2.5 x .45 x 8mm Phillips Pan
Head Machine Screw)
37 Pin Connector
Eyelid Rod
Servo Arm
Left Eyelid Servo
Left Body Latch
Eye Servo Board
(Opto-shift board)
63
