Character Top 1 – Underside View
Steering Servo
Connector
Head Turning Motor
Body Latch
Character
Control Board
66
(K.C.
™
/McGruff
Servo Arm (Set Screw)
37 Pin Connector
See Character Board Diagram for detail of
connections on the Character board.
®
)
Steering Wheel Servo
Head Turning
Feedback Pot
Body Latch
Eyes Servo Board
