Vehicle Main Electronics Board

5 Volt Regulator.
Pwr for MP3
Player and Tape
Player
Cass. 3 Volts
Switching
Pwr to Voice
Modifier and
Voice RX
Cassette
3V Power
Siren Mode
Select
Siren
Frequency
Cassette
Audio In
101 RX
Audio In
Siren Volume
Out to Audio
Amplifier
Eyelights
2 pin
58
Sensitivity Adjust:
Flashing Lights or Mouth
Headlight
Beacon
Squirter
Output 1
Output 2
Output 3
Left Drive Circuit
Andy-Reds Buster-Reds & Yellows
Reds Flash Reds Flash
Output 4
Output 5
Output 6
Right Drive Circuit
Yellows Flash Yellows Flash
Output 7
Output 8
5 V to Eye
Servo Board
(Vehicle)
Reset button
Processor
Drive Straightness
Adjustments:
Forward
Reverse
Receiver Signal In
White/Yell./Blk
Signal to Stop
Arm/Crossing
Arm Option
Signal to Eyes
Servo Board
Gray/Yell/Blk
