SmarTemp Control fx
LCD Screen Legend
Standby Mode
Auto Mode
Manual Mode
Menu Descriptions
Definitions
Time & Date allows user to properly set the current date and time. User also
Time & Date
has the ability to switch between AM/PM and 24 hour format. If the 24 hour
format is selected the date format will change to dd/mm/yyyy.
Mode
Two modes are possible:
–
Auto mode enables the pre-defined timer programs. Standard ON/OFF
functionality is still possible while in this mode.
–
Manual Mode allows the heater to be operated via the Webasto button
on the SmarTemp Control fx. While in Manual Mode, all Auto Mode
functionality is indefinitely disabled.
Note: While in manual mode the heater will continue to operate based on
the pre-defined "Duration" set by the user. See "Duration" for further
detail.
Language
Language changes between English, Spanish, and French.
Duration
Duration allows user to select heater runtime of the heater. Set range is
between 10 – 120 minutes selectable by 10 minute increments.
While using Manual Mode, the "Duration" setting will be used for the
runtime of the heater when the Webasto button is pressed.
Note: Setting the Duration run-time (in the Duration section) before setting
a timer program will default all new programs to the user defined duration
time.
Standby (Auto)
Day and Time
Auto Mode
(Timers Enabled)
Timer Active
Auto Mode
Runtime Duration Remaining
Manual Operation Mode
Runtime Duration Remaining
Standby (Manual)
Day and Time
Manual Mode
Current Day
Current Time
Heater ON
Current Day
Current Time
Heater ON
3
Installation – Operation Instructions
Default
AM/PM
mm/dd/yyyy
Manual
English
60 minutes
