MetroKit
For swing gates
with leaves up to 3.5 m,
underground installation.
Electromechanical, irreversible
gear motors, also in 24 Vdc
version, with magnetic encoder.
The 24 Vdc version with magnetic
encoder and new control unit
Moonclever (MC824H) equipped
with BlueBUS technology,
is designed for operation with
the solar power system Solemyo.
Technical specifications
Power (Vac 50 Hz)
(Vdc)
Current absorbed (line) (A)
Power absorbed
Supplied capacitor (µF)
Protection level
Torque (Nm)
Speed (Rpm)
Working temp. (°C Min/Max)
Thermal cut-out (°C)
Work cycle
Dimensions (mm)
Weight
6 SYSTEMS FOR SWING GATES KIT PRICES 2010
A more evolved range:
No welding for optimization of durability
and performance: new boxes in
cataphoresis finish (MECF),
highly resistant to corrosion, both
with mechanical stop on opening.
Reliable and resistant: motors made up
of solid internal parts in metal and bronze
alloy. New IP67 waterproof die cast
aluminium.
Total freedom of choice: release from
inside and outside, two key-operated
models or freely compatible lever version
and easily activated with just one hand.
ME3024
-
24
5
120
(W)
-
67
(IP)
250
1.4
-20 ÷ +50
-
80
(%)
390x194.5x322
11
(kg)
Dimensions
ME3000
230
-
1.2
250
10
300
1.14
140
390 mm
30
Utilisation limits
600
500
400
300
Max. gate length (m) Max. gate length (m)
The shape, the height of the gate and the weather conditions can considerably reduce
the values shown in the graph to the side. Use in windy areas 230 Vac models.
Simple to use: mechanical stop system
on closure. Standard opening max. 110°,
optional opening 360°.
24 Vdc version with magnetic encoder,
for intensive use
• easy programming by pressing
a single button
• clutch with anti-crush safety feature
• automatic memorization of limit switches
in opening and closing with self-learning
function
• pause time programming; partial opening;
slowdown during opening and closing
• the system will operate during a blackout
by means of rechargeable batteries.
