Summary of Contents for Powr-Flite Comfort Pro series
- Page 1 OPERATOR’S MANUAL & PARTS LIST Comfort Pro Backpack Vacuum BP6 - BP10 Series 6 quart model 10 quart model Hands free tool kit WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THIS EQUIPMENT. © Tacony, Inc., All rights reserved X9712 4/2013 Save These Instructions...
- Page 2 NOTES Model Number: __________________________________________________________________ Serial Number: ___________________________________________________________________ Date of Purchase: ________________________________________________________________ Retain this manual as a permanent record of your purchase.
-
Page 3: Table Of Contents
Check the carton for shipping damage. Carefully unpack and Introduction ...........3 inspect your new Powr-Flite vacuum for shipping damage. Each unit is tested and thoroughly inspected prior to shipping. Safety Instructions ........4 If damage is discovered, immediately notify the transportation company that delivered your machine and request an inspec- Storage ............4... -
Page 4: Safety Instructions
Read all instructions before using. Save These Instructions. WARNING! Following the cleaning instructions will prolong the life of your Powr-Flite vacuum. When using an electrical appliance, basic precautions should always be followed. Use only as instructed in this manual. Use only the recommended attachments and replacement parts. -
Page 5: Grounding Instructions
Cutting off the ground wire or using a cord that is not equipped with a ground plug will void the warranty on the unit. Powr-Flite will accept NO liability associated with the unit. Improper connection of the equipment-grounding conductor can result in a risk of WARNING! electric shock. -
Page 6: Operating Instructions
PeratIng InStructIonS IMPORTANT! PERFORM PROPER INSTALLATION OF HEPA BAGS AND CORD IN COMFORT PRO BACKPACK VACUUMS. Please read the following instructions carefully. They will help to get the best performance from this professional commer- cial vacuum cleaner and to maintain it in optimum condition. Always make sure the main power of the vacuum is off and the unit is not plugged in when doing any maintenance on the vacuum. - Page 7 Always unplug machine before cleaning, or making any WARNING! adjustments or repairs. The backpack vacuum has four levels of filtration: the paper vacuum bag, a micro cloth filter, a pre-motor filter and an exhaust filter. These bags and filters capture fine dust particles and protect the motor from dirt.
- Page 8 Wearing the Backpack Vacuum The backpack is designed to balance the weight of the vacuum on the hips, not the shoulders. 1. Adjust the Vari-Quick height adjuster to your back length. 2. Loosen all of the straps and place the vacuum on your back. Stabilizer Straps Shoulder Straps VariQuick Height Adjuster...
- Page 9 Warm air will be pulled into machine and circulate cooler air through mesh on Deuter harness. Active Cooling can be turned off by lowering silver metal bar. (Fig. 6) Active Cooling can stay open all the time. OPEN FIG. 5 CLOSED FIG. 6 Powr-Flite.com...
-
Page 10: Maintenance
After the motor has cooled to a safe operating temperature, locate the thermal reset switch on the bottom of the unit, under the post motor filter and push it back in. There will be a slight audible click. Now the motor will restart. ©Powr-Flite, All Rights Reserved... -
Page 11: Machine Specifications
PecIfIcatIonS 6 quart model 10 quart model Specifications and parts are subject to change without notice. Please refer to www.Powr-Flite.com for the latest schematic drawing and parts list. PRODUCT SPECIFICATIONS MODEL COMFORT PRO 6 COMFORT PRO 10 COMFORT PRO 6 PREMIUM... - Page 12 Standard Tool Kit J1006 4′ Rigid Hose Fits: BP6S - BP10S W/90° Bend & Cuff CT171 2 Bend Wand CT176 17″ Crevice Tool W/Clip CT184 Install the floor tool to the end of the 3″ Dusting Tool wand. Align the brass ring with the W/Clip B352-PF10 groove on the floor tool to ensure a...
- Page 13 oolS cheMatIcS and artS STANDARD TOOL KIT - FITS BP6S - BP10S PREMIUM TOOL KIT - FITS BP6P - BP10P ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. CARPET TOOL W/CLIP B352-PF10 CARPET TOOL W/CLIP B352-PF10 HARD FLOOR TOOL W/CLIP C352-PF20 HARD FLOOR TOOL W/CLIP C352-PF20...
-
Page 14: Schematic And Parts List
- bP6S cheMatIc and artS... - Page 15 RUBBER MOTOR MOUNT X9681 EXHAUST FILTER X9682 INLET FILTER X9683 MOTOR PLATE GASKET X9684 HOUSING BUMPER X9685 POWR-FLITE LABEL X9687 MOTOR MOUNTING BOLT X9688 TOP HARNESS SCREW X9688 8-18 HI-LO SCREW X9690 8-18 HI-LO SCREW ZINC PLATED .75" LONG X9676...
- Page 16 - bP6P cheMatIc and artS...
- Page 17 RUBBER MOTOR MOUNT X9681 EXHAUST FILTER X9682 INLET FILTER X9683 MOTOR PLATE GASKET X9684 HOUSING BUMPER X9685 POWR-FLITE LABEL X9687 MOTOR MOUNTING BOLT X9688 TOP HARNESS SCREW X9688 8-18 HI-LO SCREW X9690 8-18 HI-LO SCREW ZINC PLATED .75" LONG X9676...
- Page 18 - bP10S cheMatIc and artS...
- Page 19 RUBBER MOTOR MOUNT X9681 EXHAUST FILTER X9682 INLET FILTER X9683 MOTOR PLATE GASKET X9684 HOUSING BUMPER X9685 POWR-FLITE LABEL X9687 MOTOR MOUNTING BOLT X9688 TOP HARNESS SCREW X9688 8-18 HI-LO SCREW X9690 8-18 HI-LO SCREW ZINC PLATED .75" LONG X9676...
- Page 20 - bP10P cheMatIc and artS...
- Page 21 RUBBER MOTOR MOUNT X9681 EXHAUST FILTER X9682 INLET FILTER X9683 MOTOR PLATE GASKET X9684 HOUSING BUMPER X9685 POWR-FLITE LABEL X9687 MOTOR MOUNTING BOLT X9688 TOP HARNESS SCREW X9688 8-18 HI-LO SCREW X9690 8-18 HI-LO SCREW ZINC PLATED .75" LONG X9676...
- Page 22 IMIted arranty Powr-Flite will repair or exchange parts for your vacuum in the event of a manu- This warranty covers normal use and does not cover damage which occurs in facturing defect as follows: shipment or failure resulting from alteration, accident, misuse, abuse, neglect, or improper maintenance.
