Summary of Contents for Dynabrade 65750
- Page 1 Parts Page Reorder No. PD97•41 Effective July, 1997 Precision Tool Post Grinder Instruction Manual Models: : 65750 – 3,450 RPM (Wet), 60 Hz 2" Wide x 48" Long Abrasive Belt Machine 65751 – 2,850 RPM (Wet), 50 Hz...
- Page 2 Our obligation is contingent upon proper use of Dynabrade tools in accordance with factory recommendations, instructions and safety practices. It shall not apply to equipment which has been subject to misuse, negligence, accident or tampering in any way so as to affect its normal performance.
- Page 3 Model No. Inch (mm) Inch (mm) Inch (mm) Weight (kg) Belt Size Electrical SFPM 65750 (Wet) 17" (432) 19" (483) 18" (457) 108 lbs. (49) 2"(50) x 48"(1219) 240 V/ 1 Ph/60 Hz 3,450 7,200 (2,187) 65751 (Wet) 17" (432) 19"...
- Page 4 65750 – 3,450 RPM (Wet), 60Hz Precision Tool Post Grinder – Machine Parts Breakdown – Models 65750 and 65751 65751 – 2,850 RPM (Wet), 50Hz Item Part No. Description Qty. 66605 Housing 66608 Electric Assembly (50 Hz) 66607 Electric Assembly (60 Hz)
- Page 5 ACHINE DJUSTMENTS Belt Change/Installation: 1. Remove Belt Guard by grasping door latch (P/N 97760) and rotate 1/4 turn counter-clockwise. 2. Turn off air supply at valve (item #42). This will retract air cylinder (item #35) and thus removes tension from the belt. 3.
- Page 6 LECTRICAL AFETY NSTRUCTIONS Warning: When using electric tools, basic safety precautions should always be followed to reduce the risk of a fire, electric shock, and personal injury, including the following: Keep work area clean. Cluttered areas and benches invite accidents. Consider work area environment.
- Page 7 Visit our new Web Site via Industry.Net MROP On-Line: http://www.dynabrade.industry.net E-Mail: DynaTalk@aol.com DYNABRADE, INC., 8989 Sheridan Drive • Clarence, NY 14031-1490 • Phone: (716) 631-0100 • Fax: 716-631-2073 • International Fax: 716-631-2524 DYNABRADE EUROPE S.àr.l., Zone Artisanale • L-5485 Wormeldange—Haut, Luxembourg • Telephone: 352 76 84 94 • Fax: 352 76 84 95 ©...
