EPV Twilight Manual User Manual

Outdoor manual pull-down projection screen

Advertisement

Quick Links

Thank you for choosing the Twilight Manual projection screen! Please read through this user guide
before utilizing the screen. Correct usage and maintenance will ensure a long product life

Product Description:

The Twilight Manual is a non-electric outdoor projector screen for wall and patio installations that
brings media room quality to your outdoor spaces. Its sleek aluminum casing beautifully accessorizes
your backyard, patio, pool deck or anywhere a gathering for evening movie time is appropriate.

Outdoor Projection Screen Disclaimer

Never leave your projection screen out and exposed to direct sunlight. Regardless of screen brand,
prolonged exposure to the sun's ultraviolet radiation degrades the chemical bonds causing the material
to ultimately decompose. Photodegradation first causes the material to lose its theater-grade reflective
qualities. Eventually nature will completely destroy even synthetic materials. For this reason, the
Twilight Manual has a retractable design that allows the material to be drawn up into its protective
casing to be shielded from solar radiation.
Care & Use Instructions
Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of
the points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
To avoid damage and injury, the screen should only be operated by adults.

Pre-Installation

1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. To protect the screen from exposure to stains, keep the screen out of contact with foreign particles such
as dust, sawdust, and/or liquids.
Rev.03292022JA
Twilight Manual Series
Outdoor Manual Pull-Down Projection Screen
www.epvscreens.com
User's Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Twilight Manual and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EPV Twilight Manual

  • Page 1 Photodegradation first causes the material to lose its theater-grade reflective qualities. Eventually nature will completely destroy even synthetic materials. For this reason, the Twilight Manual has a retractable design that allows the material to be drawn up into its protective casing to be shielded from solar radiation.
  • Page 2 The installer must ensure that the fasteners used are of adequate strength and suitable for the installation location. Hardware Parts List for Twilight Manual Series A. Mounting Bracket B.
  • Page 3 Installation Instructions Please consult a professional installer, EPV Screens is not liable for faulty installations. Flush Mount to the Wall 1. Mark the location of where the screen is to be installed, drill your holes and insert the M10Anchors (B).
  • Page 4 Flush Mount to the Ceiling 1. Mark the location of where the screen is to be installed, drill your holes, and insert the M10 Anchors (B). 2. Install the Mounting Brackets (A) to the ceiling and secure with the M4x50 Screws (B). Ceiling M10 Anchor Mounting Bracket Fix Plate 1...
  • Page 5 3. Insert chains (not included) through the holes of the Suspended Ceiling Bracket Connector(D). Suspended Ceiling Bracket Connector Screen removal from the Mounting Brackets 1. Pull down on the Mounting Bracket Release Tab and remove the bottom case away from the wall/ceiling followed by the top of the case.
  • Page 6 Slow Retract Mechanism Temperate Limitation Please be aware that temperature changes will affect the Slow Retract Mechanism (SRM) operation/speed. Below are the expectations of the SRM based on the temperature in your outdoor environment. Note: If the screen does not fully retract entirely on its own, it is not a defect but just a limitation on the SRM operation.
  • Page 7 2. Drive the Ground Stake (F) into the ground and stretch the Elastic String (H) in the direction of the Ground Stake (F) to secure screen to the ground and supply adequate tension to the screen. Carabiner Iron Ring Elastic String Ground Stake Ground For more information, technical support or your local EPV Screens contact, www.epvscreens.com please visit www.epvscreens.com Rev.03292022JA...
