mounting the crank handle & extension bar
Mount the crank handle to the Cine Follow Focus
One to enable the focus to be adjusted with
minimum effort.
To mount the crank handle:
1
Connect the crank
handle to the 12mm
square drive of the
handwheel.
2
Rotate the crank
handle to adjust the
focus.
20
For larger camera packages a 70 mm extension
bar can be used.
To mount the extension bar:
1
Push-fit the extension bar onto the handwheel and
main bridge.
2
Turn the lock levers clockwise
to secure the extension bar.
