marking discs & witness mark
Set the focal distances for the Cine Follow Focus One. Using
a suitable pen mark the lens focal reference points on the
marking disc. The handwheel is supplied ready with a
marking disc.
To remove the marking disc:
Pull the marking disc off the handwheel.
To replace the marking disc:
a
Ensure that the cutout on the marking disc is
aligned with the point on the handwheel.
b
Slide the marking disc over the handwheel and
push into position, until it clicks.
18
To move the witness mark:
CAUTION: Always remove the marking disc before cleaning. Do not
use solvents on the CFF-1. Follow the instructions supplied
with the marking pen when cleaning the marking discs.
a
Loosen the index on
top of the witness
mark.
b
Rotate the witness
mark to the focus
point on the marking
disc. Secure into
position by tightening
the index.
