chipKIT™ MX3 Board Reference Manual
Arranged by MCU Port and Bit
PIC32 Connector Digital
Pin # Pin #
16 JC-07
15 JC-08
14 JD-01
13 JE-10
12 JE-09
11 JE-08
17 N/A
18 N/A
21 JC-01
22 JD-04
23 N/C
24 N/C
27 JD-07
28 JD-10
29 JC-04
30 N/C
39 N/A
47 N/A
48 N/A
40 N/A
46 JC-09
49 JC-10
50 JD-02
51 JD-08
52 JB-09
53 JB-08
54 JB-07
55 JB-10
42 JE-07
43 JB-01
44 JD-03
45 JD-09
60 JA-01
61 JA-02
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
MCU
PIC32 Signal Name
Pin # Port Bit
20 RB00 PGED1/PMA6/AN0/VREF+/CVREF+/CN2/RB0
21 RB01 PGC1/AN1/VREF-/CVREF-/CN3/RB1
24 RB02 C2IN-/AN2/SS1/CN4/RB2
39 RB03 C2IN+/AN3/CN5/RB3
38 RB04 C1IN-/AN4/CN6/RB4
37 RB05 C1IN+/AN5/CN7/RB5
N/A RB06 PGEC2/AN8/OCFA/RB6
N/A RB07 PGED2/AN7/RB7
16 RB08 U2CTS/C1OUT/AN8/RB8
27 RB09 PMA7/C2OUT/AN9/RB9
N/C RB10 TMS/CVREFOUT/PMA13/AN10/RB10
N/C RB11 TDO/PMA12/AN11/RB11
28 RB12 TCK/PMA11/AN12/RB12
31 RB13 TDI/PMA10/AN13/RB13
19 RB14 PMALH/PMA1/U2RTS/AN14/RB14
N/C RB15 PMALL/PMA0/AN15/OCFB/CN12/RB15
N/A RC12 OSC1/CLKI/RC12
N/A RC13 SOSCI/CN1/RC13
N/A RC14 SOSCO/T1CK/CN0/RC14
N/A RC15 OSC2/CLKO/RC15
22 RD00 OC1/RD0
23 RD01 OC2/RD1
25 RD02 OC3/RD2
29 RD03 OC4/RD3
14 RD04 PMWR/OC5/IC5/CN13/RD4
13 RD05 PMRD/CN14/RD5
12 RD06 CN15/RD6
15 RD07 CN16/RD7
36 RD08 IC1/RTCC/INT1/RD8
8 RD09 IC2/U1CTS/INT2/RD9
26 RD10 IC3/PMCS2/PMA15/INT3/RD10
30 RD11 IC4/PMCS1/PMA14/INT4/RD11
0 RE00 PMD0/RE0
1 RE01 PMD1/RE1
Notes
A2
A3
A4
A10
A9
A8
A0
A5
A6
A7
A1
X1, system clock
oscillator
X2, secondary
oscillator
X2, secondary
oscillator
X1, system clock
oscillator
PIN_OC1
PIN_OC2
PIN_OC3
PIN_OC4
PIN_OC5
