chipKIT™ MX3 Board Reference Manual
Arranged by Connector Pin Number and Digital Pin Number
PIC32 Connector
Pin # Pin #
60 JA-01
61 JA-02
62 JA-03
63 JA-04
64 JA-07
1 JA-08
2 JA-09
3 JA-10
43 JB-01
33 JB-02
34 JB-03
35 JB-04
54 JB-07
53 JB-08
52 JB-09
55 JB-10
21 JC-01
32 JC-02
31 JC-03
29 JC-04
16 JC-07
15 JC-08
46 JC-09
49 JC-10
14 JD-01
50 JD-02
44 JD-03
22 JD-04
27 JD-07
51 JD-08
45 JD-09
28 JD-10
8 JE-01
6 JE-02
5 JE-03
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Digital MCU Port
PIC32 Signal Name
Pin # Bit
0 RE00 PMD0/RE0
1 RE01 PMD1/RE1
2 RE02 PMD2/RE2
3 RE03 PMD3/RE3
4 RE04 PMD4/RE4
5 RE05 PMD5/RE5
6 RE06 PMD6/RE6
7 RE07 PMD7/RE7
8 RD09 IC2/U1CTS/INT2/RD9
9 RF03 U1TX/SDO1/RF3
10 RF02 U1RX/SDI1/RF2
11 RF06 U1RTS/BCLK1/SCK1/INT0/RF6
12 RD06 CN15/RD6
13 RD05 PMRD/CN14/RD5
14 RD04 PMWR/OC5/IC5/CN13/RD4
15 RD07 CN16/RD7
16 RB08 U2CTS/C1OUT/AN8/RB8
17 RF05 PMA8/U2TX/SCL2/CN18/RF5
18 RF04 PMA9/U2RX/SDA2/CN17/RF4
19 RB14 PMALH/PMA1/U2RTS/AN14/RB14
20 RB00 PGED1/PMA6/AN0/VREF+/CVREF+/CN2/RB0
21 RB01 PGC1/AN1/VREF-/CVREF-/CN3/RB1
22 RD00 OC1/RD0
23 RD01 OC2/RD1
24 RB02 C2IN-/AN2/SS1/CN4/RB2
25 RD02 OC3/RD2
26 RD10 IC3/PMCS2/PMA15/INT3/RD10
27 RB09 PMA7/C2OUT/AN9/RB9
28 RB12 TCK/PMA11/AN12/RB12
29 RD03 OC4/RD3
30 RD11 IC4/PMCS1/PMA14/INT4/RD11
31 RB13 TDI/PMA10/AN13/RB13
32 RG09 SS2/PMA2/CN11/RG9
33 RG08 SDO2/PMA3/CN10/RG8
34 RG07 SDI2/PMA5/CN9/RG7
Notes
PIN_OC5
A0
A1
A2
A3
PIN_OC1
PIN_OC2
A4
PIN_OC3
A5
A6
PIN_OC4
A7
JP8 in M
position
JP6 in M
position
Page 21 of 24
