chipKIT™ MX3 Board Reference Manual
35 JB-04
36 J2-3,J2-4
37 J2-1,J2-2
38 N/A
39 N/A
40 N/A
41 N/A
42 JE-07
43 JB-01
44 JD-03
45 JD-09
46 JC-09
47 N/A
48 N/A
49 JC-10
50 JD-02
51 JD-08
52 JB-09
53 JB-08
54 JB-07
55 JB-10
56 N/A
57 N/A
58 N/A
59 N/A
60 JA-01
61 JA-02
62 JA-03
63 JA-04
64 JA-07
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
11 RF06 U1RTS/BCLK1/SCK1/INT0/RF6
40 RG03 SDA1/RG3
41 RG02 SCL1/RG2
N/A VDD
N/A RC12 OSC1/CLKI/RC12
N/A RC15 OSC2/CLKO/RC15
N/A VSS
36 RD08 IC1/RTCC/INT1/RD8
8 RD09 IC2/U1CTS/INT2/RD9
26 RD10 IC3/PMCS2/PMA15/INT3/RD10
30 RD11 IC4/PMCS1/PMA14/INT4/RD11
22 RD00 OC1/RD0
N/A RC13 SOSCI/CN1/RC13
N/A RC14 SOSCO/T1CK/CN0/RC14
23 RD01 OC2/RD1
25 RD02 OC3/RD2
29 RD03 OC4/RD3
14 RD04 PMWR/OC5/IC5/CN13/RD4
13 RD05 PMRD/CN14/RD5
12 RD06 CN15/RD6
15 RD07 CN16/RD7
N/A VCAP/VDDcore
N/A ENVREG
42 RF00 RF0
43 RF01 RF1
0 RE00 PMD0/RE0
1 RE01 PMD1/RE1
2 RE02 PMD2/RE2
3 RE03 PMD3/RE3
4 RE04 PMD4/RE4
X1, system clock
oscillator
X1, system clock
oscillator
PIN_OC1
X2, secondary
oscillator
X2, secondary
oscillator
PIN_OC2
PIN_OC3
PIN_OC4
PIN_OC5
PIN_LED1, (LD4)
PIN_LED2, (LD5)
