Instruction Manual
Basic Rack PDU
VP7541 and VP9571A
VertivCo.com/geist

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP9571A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vertiv VP9571A

Summary of Contents for Vertiv VP9571A

  • Page 1 Instruction Manual Basic Rack PDU VP7541 and VP9571A VertivCo.com/geist...

  • Page 2: Table Of Contents

    Table of Contents Specifications ......................3 Overview ................................. 3 Environmental ..............................3 Temperature ..............................3 Humidity ................................3 Elevation ................................. 3 Electrical ................................3 Receptacle Ratings ............................3 EMC Verification ............................. 3 Installation ........................4 Instructions ..............................4 Guidelines ............................... 4 Mounting ........................

  • Page 3: Specifications

    30 Amp AC Mains circuit. The PDUs are designed to be powered by a single phase AC input circuit. The Vertiv Basic Rack PDUs covered by this manual are available in vertical or horizontal configurations rated 208-240V and can be optionally configured with a Vertiv Power Meter that provides local monitoring and display of Current, Voltage, Wattage, and Power Factor.

  • Page 4: Installation

    BASIC RACK PDU Installation Instructions 1. Using appropriate hardware, mount PDU to rack (see Mounting section for additional instructions. 2. Plug PDU into de-energized 30 Amp branch circuit receptacle.** 3. Connect devices into PDU’s output receptacles. It is recommended that the devices are turned off until all devices are connected to PDU 4.

  • Page 5: Mounting

    BASIC RACK PDU Mounting Full Length Bracket Using the full length bracket, mount PDU to rack as shown Mini "L" Brackets (SLB-4)
  • Page 6 Vertical Extension Brackets (VCB-1) Using the vertical extension brackets, attach PDU to rack as shown Toolless Mounting Hardware (11621) Secure toolless mounting buttons to PDU as shown. Use toolless buttons with key-holed slots built into cabinet or with optional Vertiv key-holed brackets.
  • Page 7 BASIC RACK PDU Toolless Full Length Bracket (TLFL) Using full length toolless bracket and toolless mounting buttons, attach PDU to rack as shown Single Side Mount 2 Unit Brackets (TSMX2) Using single side mount 2 unit brackets and toolless mounting buttons, attach PDU to rack as shown...
  • Page 8 BASIC RACK PDU Offset/Side Mount Brackets (EZB-1) Using the offset/side mount brackets, attach PDU to rack as shown. 7" Extension Brackets (XB-7) Using the 7” extension brackets, attach PDU to rack as shown...
  • Page 9 BASIC RACK PDU Flush Mount Brackets (FM) Using flush mount brackets, attach PDU to rack as shown Adjustable Mount Brackets (AM) Using adjustable mount brackets, attach PDU to rack as shown...
  • Page 10 BASIC RACK PDU Panel Mount Brackets (PM) Using panel mount brackets, attach PDU to rack as shown 23" Conversion Mounting Brackets (23-RM) Using conversion mounting brackets, attach 19” PDU to 23” rack as shown...
  • Page 11 BASIC RACK PDU Cable Mount Bracket (CMB-1) Attach cable mount bracket to PDU as shown; use tie-wraps to secure cords to bracket 19" Horizontal/Panel Mount Brackets (7938) Using the 19” horizontal/panel mount brackets, attach PDU to rack as shown...

  • Page 12: Optional Local Monitoring

    Optional Local Monitoring Power Meter The Vertiv PM-1 power meter is a low-power, high accuracy meter capable of measuring true RMS Current, Voltage, Power, and Power Factor. These values are individually shown on an easy to read, 4-digit LED Display, which continuously scrolls through the four different measured values. Each one of these displayed parameters is defined below.

  • Page 13: Service/Tech Support

    BASIC RACK PDU Service/Tech Support Service and Maintenance No service or maintenance is required. Do not attempt to open the PDU or you may void the warranty. No serviceable parts inside. It is recommended that power be removed from the unit before installing or removing any equipment.
  • Page 14 BASIC RACK PDU Thank You For Purchasing Your Vertiv Product VertivCo.com/geist...
