Model 165
• Install in Place of Standard Thermostat
During Construction
• Fixed Setpoint of 65˚ for Heating Applications
• Tamper-proof Design Prevents
Temperature Adjustment
• Sturdy Enclosure Protects Switch from Drywall
Dust, Painting and Mudding
• Lowers Costs–Can be Reused from Job to Job
Construction
Thermostat
®
Pub. No. 165-100-003
Advertisement
Table of Contents
Related Manuals for Braeburn 165
Summary of Contents for Braeburn 165
- Page 1 • Install in Place of Standard Thermostat During Construction • Fixed Setpoint of 65˚ for Heating Applications • Tamper-proof Design Prevents Temperature Adjustment • Sturdy Enclosure Protects Switch from Drywall Dust, Painting and Mudding • Lowers Costs–Can be Reused from Job to Job Pub. No. 165-100-003...
-
Page 2: Installation Instructions
Installation Instructions: 1. Confirm power to heater controls is OFF. 2. Attach first black wire of the 165 construction thermostat to 24 VAC wire (red). 3. Attach second black wire of the thermostat to the heating device wire (white) and the fan wire (green) for electric heat applications.
