Coffing Hoists Concert Series Operating, Maintenance & Parts Manual page 27

Parts List for Chaining Parts
Ref Description
No.
1 Housing
2 Transmission Cover
3 Electrical Cover
4 Anchor Pin (2 ton only)
5 Anchor (2 ton only)
6 Chain Stripper
7 Chain Stop Kit
(Kits include halves, sleeve and retaining ring)
8 Load Chain
9 Attachment Pin
10 Retaining Clip
11 1/4-20UNC x 1¼"
Socket Head Cap Screw
12 Bottom Block Assembly
1 ton & Under
13 1/4-20UNC x 1¼"
Socket Head Cap Screw
14 1/4" Internal-tooth
Lockwasher
15 Load Block Frame
16 Load Block Pin
17 Slotted Hex Nut
18 Bearing
19 Latch Kit
20 Bottom Hook Assembly
with Latch for 1 Ton & Under
* Replacement chain is sold by the foot. For single-chained models, add 2 ft to the lift for the total amount of feet.
For double-chained models, double the lift and add 3 ft.
For more information contact: Sievert Crane and Hoist, (708) 771-1600, parts@sievertelectric.com, www.sievertcrane.com
Part Qty Ref
No. No.
JM3533 1 21
JM34 1
JM36 1 22
JM111 1 23
JM109 1 24
JM254 1 25
75JG6K 1 26
27
JL19-1 * 28
JM18-1 1 29
H5597 1 30
31
S49-77 1 32
913JG3AS 1
S49-77 2
H4134 2
30J14 2
18J8 1
H3986P 1
JF510 1
4X1304 1
3JG20S 1
27
Description
Bottom Block Assembly
for 2 Ton
3/8-24 Hex Locknut
Load Block Screw
Load Block Frame
Sheave Shaft Assembly
Sheave Shaft
Sheave & Bearing Assembly
Roll Pin
3/8-24 Hex Locknut
Bearing
Latch Kit
Bottom Hook Assembly
with Latch for 2 Ton
Country Club Road
P.O. Box 779
Wadesboro, NC 28170 USA
TEL: (800) 477-5003
FAX: (800) 374-6853
Part Qty
No.
JF914-6 1
H3964P 2
H2403P 2
JF30-1 2
JF917-1 1
JF122-1 1
JF916 1
H5234 2
H3991P 1
JF511 1
4X1305 1
3KG1W 1
