Parts List for Gearbox
Ref.
No.
Description
1
Sheave Housing
2
Transmission Gasket
3
Transmission Cover
(Includes Oil Seals)
4
Spring Washer
5
O-ring
6
Pressure Relief Fitting
7
Chain Guide
8
Oil Plug - Drain
9
Oil Plug - Fill
10
Oil Plug - Level
11
Oil Seal
12
Screw, HWH Self-threading
13
Motor Coupling
14
Bearing
15
Input Pinion
8 & 16 fpm
32 fpm
16
Retaining Ring
17
Brake Adapter
18
Bearing for 8 & 16 fpm
19
High Speed Pinion for 8 & 16 fpm
20
Intermediate Pinion
1/2 ton, 16 fpm
1 & 2 ton
21
Bearing
22
Output Pinion
23
Overload Clutch Assembly
1/2 ton, 16 fpm
1/2 ton, 32 fpm
1 & 2 ton
24
Retaining Ring
25
Bearing
26
Bearing
27
Spacer - Load Sheave
28
Load Sheave-9/32" Chain
29
Load Sheave Shaft
30
Stub Shaft - Limit Switch Drive
31
Oil Seal
32
Retaining Ring
33
Output Gear
34
Dowel Pin
*
Gear Oil
* Not Shown
For more information contact: Sievert Crane and Hoist, (708) 771-1600, parts@sievertelectric.com, www.sievertcrane.com
25
Country Club Road
P.O. Box 779
Wadesboro, NC 28170 USA
TEL: (800) 477-5003
FAX: (800) 374-6853
Part
No.
Qty
JM3533
1
JM560
1
JM34
1
360J1
1
H5605
1
SK1912-21W
1
JM273
1
H6297
1
H6296
1
H6295
1
561K2
3
H2693P
5
JM107
1
500K33
2
JL400B
1
JL400-1
1
H5501
3
JM142
1
500K34
2
JL426
1
JL402A
1
JL403A
1
500K39
2
JL401
1
591JG16
1
591JG21
1
591JG17
1
H5503
2
500K28
1
P003255
1
JM127
1
JF16-3
1
JM132
1
JM140
1
011612800
1
H5598
1
JL421
1
H5382
2
H7642
1
pt
½
