Coffing Hoists Concert Series Operating, Maintenance & Parts Manual page 20

Country Club Road
P.O. Box 779
Wadesboro, NC 28170 USA
TEL: (800) 477-5003
FAX: (800) 374-6853
8
Parts List for Electrical Parts, 3-Phase
Ref Description
No.
1 Transmission Cover
2 Panel Plate
3 Reversing Contactor*
24V Coil
115V Coil
4 Transformer*
Pri.: 230/460V, Sec.: 24V
Pri.: 230/460V, Sec.: 115V
Pri.: 208V, Sec.: 24V
Pri.: 208V, Sec.: 115V
Pri.: 380V, Sec.: 24V
Pri.: 380V, Sec.: 115V
Pri.: 415V, Sec.: 24V
Pri.: 415V, Sec.: 115V
Pri.: 575V, Sec.: 24V
Pri.: 575V, Sec.: 115V
* Coil voltage of the contactor and the secondary voltage of the transformer are the same. This is referred to as the
control voltage. Standard units are supplied with 115V Control.
For more information contact: Sievert Crane and Hoist, (708) 771-1600, parts@sievertelectric.com, www.sievertcrane.com
Figure 14 - Electrical Parts, 3-Phase
16
13
14
15
9
16
Part
No.
JM34
257UJ200
28860
24799
821J432
821J431
821J472
821J471
821J482
821J481
821J492
821J491
821J452
821J451
1
7
10
10
14
4
7
Qty Ref Description
No.
1 5 Terminal Block, 230/460V
1 6 End Plate, 230/460V
7 End Clamp
1 8 Power Pigtail
1 3-Phase (4 cond.)
9 Control Pigtail
1 10 Panel Standoff Spacer
1 11 1/4" Internal-tooth Lockwasher
1 12 1/4-20UNC X 4" Screw
1 13 8-32UNC X 5/16" Screw
1 14 #8 External-tooth Lockwasher
1 15 1/4" Flatwasher
1 16 10-24UNC X 1/2" Screw
1
1
1
20
6
5
2
11
11
12
3
Part
No.
909J10
909J12
909J17
953JM1
299JG4-2
200J4
H4134
H1027P
H2751
H4158
H4002P
H2970
12
Qty
3
1
2
1
1
3
3
3
2
2
1
2
