8
(‡) Refer to the motor nameplate for part number
voltage, full load amperage, horsepower, and
other motor information.
Parts List for Motor, 3-Phase
Ref.
No.
Description
1
Motor
1/2 hp, 230/460V-3Ph-60Hz
1 hp, 230/460V-3Ph-60Hz
1/2 hp, 190/380V-3Ph-50Hz
1 hp, 190/380V-3Ph-50Hz
1/2 hp, 208V-3Ph-60Hz
1 hp, 208V-3Ph-60Hz
1/2 hp, 415V-3Ph-50Hz
1 hp, 415V-3Ph-50Hz
1/2 hp, 575V-3Ph-60Hz
1 hp, 575V-3Ph-60Hz
* Not available as an individual part.
For more information contact: Sievert Crane and Hoist, (708) 771-1600, parts@sievertelectric.com, www.sievertcrane.com
Figure 11 - Motor, 3-Phase
1
9
4
7
5
Part
No.
Qty.
863JX2
1
863JX4
1
863JX2
1
863JX4
1
863JX10
1
863JX12
1
863JX26
1
863JX28
1
863JX6
1
863JX8
1
‡
3
6
2
Ref.
No.
Description
2
Stator Assembly
3
Rotor Assembly
4
End Shield
5
Rear Bearing
6
Front Bearing
7
Shim Washer
8
Thru Bolt (1-Speed)
9
#10 Spring Lockwasher
17
Country Club Road
P.O. Box 779
Wadesboro, NC 28170 USA
TEL: (800) 477-5003
FAX: (800) 374-6853
Part
No.
Qty.
*
1
*
1
35EP3100D15 1
500K3
1
732012C
1
JL4301-01
1
HA3100A56
4
H4082P
4
