Summary of Contents for CITC A/C Air Launcher 101050
- Page 1 A/C AIR LAUNCHER Operating Instructions P/N 101050 (120 VAC) P/N 101051 (230 VAC)
- Page 2 And finally, we believe you will enjoy years of great effects if you care for and maintain your A/C AIR LAUNCHER CITC 1420 80 SW #D EVERETT, WA 98203 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Set of Equipment Supplied 2. Accessories and Parts 3. Confetti Products 4. Description 5. Safety Instructions 6. Operating the A/C AIR LAUNCHER 6.1 Assembly 6.2 Loading 6.3 Optional backpressure cap 6.4 Pressurizing the tank 6.5 Firing the A/C Air Launcher 6.6 Troubleshooting 7. -
Page 4: Set Of Equipment Supplied
1. Set of Equipment Supplied 1 A/C AIR LAUNCHER (120VAC: P/N 101050; 230VAC P/N 101051) Instruction booklet 2. Accessories and Parts Spare 2” (5cm) Barrel P/N 350020 DMX FX-15 Switchpack 120 VAC, 15A relay P/N 250051, ... -
Page 5: Description
WARNING! Never use a confetti-launching product if there are open flames present. Use only tissue-type confetti or streamers that are flame retardant as sold by CITC. Never use paper dots or heavy paper confetti. Pressurize up to maximum 100 PSI (6.9 bar) only! -
Page 6: Operating The A/C Air Launcher
6. Operating the A/C AIR LAUNCHER Assembly • Secure a good location for the machine to rest solidly on the floor. • Secure the launcher so it will not be moved after it is aimed • Anchor as needed with straps, screws, or sandbags. •... -
Page 7: Pressurizing The Tank
• Note: the lifting cups are sometimes reusable if you can find them, however the backpressure caps may need replacing if they tear when blown off. Pressurizing the tank • Fill tank from your own air source. Use an air compressor capable of up to 100 PSI, a tank of compressed air, or even a tire pump. -
Page 8: Troubleshooting
6.6 Troubleshooting If you plug in the transformer, the solenoid immediately releases the air. Always be sure your power is off before loading and pressurizing. As soon as you plug it in, it will fire. Air is leaking and won’t hold pressure: Check all connections with soap and water and tighten as necessary. -
Page 9: Limited Warranty Conditions
Our customer service department will respond to your problems immediately. Subject to the following conditions, CITC will repair any defect or fault in the unit if it is caused by a proven factory defect within one year of delivery to the end user. - Page 10 CITC. The right of limited warranty service is also lost if a fluid other than appropriate CITC fluid has been used or if units are sent in without first emptying the equipment of fluid.
