Summary of Contents for CITC ShotMax 100260
- Page 1 SHOTMAX Operating Instructions P/N 100260 (120 VAC) P/N 100265 (230 VAC)
- Page 2 take some time to read the manual carefully. We believe you will enjoy years of great confetti effects if you care for and maintain your SHOTMAX CITC 1420 80 St. SW, #D Everett, WA 98203 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Equipment Supplied 2. Accessories 3. Confetti Products 4. Description 5. Safety Instructions 6. Operating the Shotmax™ 6.1 Selecting The Location 6.2 Electrical Power Requirements 6.3 Hooking Things Up 6.4 Operating the Machine 6.5 Optional DMX Control 6.6 Rest Period 6.7 Troubleshooting 7. -
Page 4: Equipment Supplied
Bracket w/ Mounting Hardware Barrel 2” x 24” (5cm x 61cm) tube w/ Male Fitting Tube w/ Angled Feeder Tip 2” x 24” (5cm x 61cm) Tube w/ Angled Feeder Tip 2” x 5” (5cm x 13cm) ... -
Page 5: Confetti Products
3. Confetti Products Also check our website (www.citcfx.com) for a complete selection of confetti and streamer products. CONFETTI - SPEED LOAD Confetti stacked in 1" x 18" (2.5cm x 46cm) soft-sleeve. Just slide in then pull sleeve Multi-color mix or Solid colors in stock. Custom mix by request. Tissue Confetti - Solid colors, rainbow, and Red, White &... -
Page 6: Description
4. Description of the ShotMax The ShotMax with its 24” x 2” (61cm x 5cm) cannon uses continuous vacuum suction to shoot out product simultaneously and continuously. It is capable of shooting continuous confetti to approximately 35 feet (10.7m) and streamers to 50 feet (15.2m). Simple and uncomplicated, the product is never touched by blades or a motor, and is built with safety standards in mind! Compared to the competition, the noise level is reduced by 75%. -
Page 7: Operating The Shotmax
Selecting the Location Secure a good location for the machine to rest solidly on the floor or suspended so that the output of the machine will not be restricted. If suspending the unit, you must use the optional safety cable. Make sure that your unit is pointed in a direction that leaves an open area out in front and can travel 50ft (13m) without restriction. -
Page 8: Optional Dmx Control
vacuumed. Note: The angled end allows air with the product to be drawn into tube. This prevents clogging. • This machine is to be used with soft materials only! Do not use this to launch any other items. Injury can occur if improperly used. Use of any fluids through the machine is prohibited. -
Page 9: Service And Maintenance
Service and Maintenance Care of your ShotMax will give you years of service. Cleaning your unit is going to pay off in constant good performance. After use, detach hose and inspect hose and Y-connector for clogs. Clear any product or debris from air vents of machine housing. Inspect to make sure nothing has gotten inside the motor case. -
Page 10: Limited Warranty Conditions
Our customer service department will respond to your problems immediately. Subject to the following conditions, CITC will repair any defect or fault in the unit if it is caused by a proven factory defect within one year of delivery to the end user. - Page 11 CITC. The right of limited warranty service is also lost if a fluid other than appropriate CITC fluid has been used or if units are sent in without first emptying the equipment of fluid.
