- Page 1 SUPER FOAM DOME Operating Instructions P/N 100216 (120 VAC)
- Page 2 And finally, we believe you will enjoy years of great foam effects if you care for and maintain your SUPER FOAM DOME CITC 1420 80 St. SW #D Everett, WA 98203 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Set of Equipment Supplied 2. Accessories 3. Description 4. Safety Instructions 5. Operating the Super Foam Dome 5.1 Selecting the location 5.2 Electrical Power Requirements 5.3 Hooking things up 5.4 Operating the machine 5.5 Cleanup 5.6 Troubleshooting 6. Service and Maintenance 6.1 Super Foam Dome Pump Information 6.2 Getting the most from your Super... - Page 4 1. Set of Equipment Supplied 1 Super Foam Dome Unit 1 Super Foam Dome pump with fittings 4’ garden hose with male end for pump intake GFI Box Assembly 25’ plastic tubing w/2ea push-con fittings ...
-
Page 5: Safety Instructions
4. Safety instructions WARNING: FAILURE TO FOLLOW ALL SAFETY RULES AND INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY TO YOURSELF OR OTHER PARTICIPANTS OF THIS EFFECT. RISK OF ELECTRICAL SHOCK: 1. Keep all electrical appliances away from the foam area. 2. -
Page 6: Operating The Super Foam Dome
5. Operating the Super Foam Dome 5.1 Selecting the location Make sure unit is in a well-supported and secure location before supplying power and fluid to unit. The height of the machine above the drum decides how fast it will pump fluid. The higher the machine, the slower the fluid will flow through to the Super Foam Dome . -
Page 7: Hooking Things Up
Discontinue use and remove to fresh air. As with all surfactants, care must be used at all times. Contact CITC for further questions or copies of the MSDS at 1- 888-786-CITC or see it posted on our website at www.citcfx.com... -
Page 8: Operating The Machine
It is important to deploy the plastic shield enclosed in the unit. This plastic shield prevents most of the foam or bubbles from being sucked back inside the Super Foam Dome fan intake. Slide the shield half #1 onto the fan outlet, behind the modulator (sock) and under the tip of the molded handle located on the blower and molded strip under machine. -
Page 9: Cleanup
5.5 Clean up Place a bucket under the modulator to catch falling water, and run 1-gallon fresh water through system each night to clean and freshen equipment. Unplug GFI from power source. Wipe off output end and any excess foam. Make sure no fluid has dripped or splashed on the electrical components. -
Page 10: Service And Maintenance
o If still clogged at the nozzle, remove unit to outside location and connect a high pressure hose to the nozzle connection. While holding the unit in its hung position so the water will run down and out of the unit, (not up or in the unit), turn on the water to pressurize the nozzle inside and clean the nozzle. -
Page 11: Technical Data
7. Technical Data Super Foam Dome 120V Technical Data P/N 100216 Super Foam Dome Dimensions 19” x 19” x 19” (48cm x 48cm x 48cm) Super Foam Dome Weight 56 lbs (25.5 kg) (including pump) Shipping Dimensions 25” x 25” x 25” (63 x 63 x 63cm) Shipping Weight 65 lbs (29.5 kg) Super Foam Dome... - Page 12 Our customer service department will respond to your problems immediately. Subject to the following conditions, CITC will repair any defect or fault in the unit if it is caused by a proven factory defect within one year of delivery to the end user.
- Page 13 CITC. The right of limited warranty service is also lost if a fluid other than appropriate CITC fluid has been used or if units are sent in without first emptying the equipment of fluid.
