Pin on EXT3
9
10
11
12
13
14
15
16
17
18
19
20
4.1.2.

Other Headers

In addition to the Xplained Pro standard extension headers, SAM4N Xplained Pro has three additional
headers with spare signals that offers access to the I/O of the microcontroller that are otherwise not easily
available elsewhere or might be favorable to have collected together. All headers have a pitch of 2.54mm.
Table 4-4. SPARE SIGNALS Header 1
Pin on header
1
2
3
4
5
6
7
8
9
10
11
12
SAM4N pin Function
PB2 WKUP12
PB3 GPIO
PA3 TWD0
PA4 TWCK0
PB10 URXD3
PB11 UTXD3
PC7 NPCS2
PA13 SPI_MOSI
PA12 SPI_MISO
PA14 SPI_SCK
- -
- -
SAM4N pin Function
PA4 TWCK0
PA28 TCLK1
PA29 TCLK2
PC25 TCLK3
PC28 TCLK4
PC31 TCLK5
PC16 PCK0
PC17 PCK1
PA31 PCK2
PB4 PWM2
- -
- -
Shared functionality
EXT1
EXT1, SPARE HEADER1
EXT1, EXT2
EXT1, EXT2
EXT1, EXT2
GND
VCC
Shared functionality
EXT1, EXT3
VCC
GND
