Summary of Contents for dji Phantom 4 RTK

Page 1 v1.4 User Manual 2018.10...
Page 2: Information
This document supports high resolution printing. Information There are two kinds of altitudes displayed in the DJI GS RTK app, absolute altitude and relative altitude. Absolute altitude: The geographical attribute, in relation to longitude and latitude. Relative altitude: The altitude data of the operation tasks relative to the Home Point. In the same operation, the absolute altitude for the same point during the operation will vary when taking off from locations with dif- ferent elevations.
Page 3: Table Of Contents
Contents Information Using this manual Legends Read Before the First Flight Watch the Tutorial Videos Download the DJI Assistant 2 for Phantom Product Profile Introduction Features Highlights Installation Aircraft Overview Remote Controller Overview Aircraft Profile Flight Modes Aircraft Status Indicators...
Page 4 GEO (Geospatial Environment Online) System Flight Restrictions GEO Unlocking Preflight Checklist Calibrating the Compass Starting/Stopping the Motors Stopping Motors Mid-flight Flight Test DJI Assistant 2 for Phantom Installation and Launching Using DJI Assistant 2 for Phanto Appendix Specifications Updating the Firmware © 2018 DJI All Rights Reserved.
Page 6: Product Profile
Image data from the Phantom 4 RTK can be used to generate maps for field planning when operating a DJI AGRASTM aircraft. Users can also import photos to the DJI PC GS Pro application or third-party mapping software to composite highly accurate maps for different applications.
Page 7 Phantom 4 RTK User Manual 2. Attaching the Propellers Mount the propellers with black propeller rings to the motors with black dots. Mount the propellers with sliver propeller rings to the motors without black dots. Press the propeller down onto the mounting plate and rotate in the lock direction until it is secured.
Page 8 SIM card are functioning properly. The Phantom 4 RTK remote controller can access the Internet using a 4G dongle with SIM card or Wi-Fi signal. For UK, EU, ACUK, or ACEU versions, a Network RTK server can only be accessed using a 4G dongle with SIM card.
Page 9: Aircraft Overview
Phantom 4 RTK User Manual Aircraft Overview 1. Onboard D-RTK Antenna 2. Propellers 3. Motors 4. Front LEDs 5. Forward Vision System 6. Gimbal and Camera 7. Intelligent Flight Battery 8. Aircraft Status Indicator 9. Rear Vision System 10. Infrared Sensing System 11.
Page 10: Remote Controller Overview
12. RTH Status LED Relays aircraft control signals. Circular LED around the RTH button. Displays RTH status. 2. Display Device Android-based to run the DJI MG app. 13. RTH Button Press and hold this button to initiate Return to 3. Speaker Home (RTH).
Page 11 Phantom 4 RTK User Manual 21. Button C1 Press Button C1 to switch between Map View and Camera View. 22. Button C2 When you are planning a Waypoint Flight operation, it adds a waypoint. The button is disabled in any other operations.
Page 13: Aircraft
Flight Modes The Phantom 4 RTK uses a DJI dedicated flight controller, which provides the flight modes below: P-mode (Positioning): P-mode works best when the GNSS signal is strong. The aircraft utilizes the GNSS / RTK module and Vision System to automatically stabilize itself, navigate between obstacles, and perform a Photogrammetry or Waypoint Flight operation.
Page 14: Aircraft Status Indicators
Phantom 4 RTK User Manual Aircraft Status Indicators The Phantom 4 RTK has Front LEDs and Aircraft Status Indicators. The positions of these LEDs are shown in the figure below: Aircraft Status Indicators Front LEDs The Front LEDs show the orientation of the aircraft. The Front LEDs glow solid red when the aircraft is turned on to indicate the front (or nose) of the aircraft.
Page 15: Return To Home (Rth)
RTH while the Forward Vision System is enabled. Updating the Home Point You can update the Home Point in the DJI GS RTK app during flight. There are two options for setting the Home Point: 1.
Page 16 Low Battery RTH The low battery level failsafe is triggered when the DJI Intelligent Flight Battery is depleted to a point that may affect the safe return of the aircraft. The user can cancel the RTH procedure by pressing the RTH button on the remote controller.
Page 17 Phantom 4 RTK User Manual Battery Level Aircraft Status DJI GS RTK Remark Flight Instructions Warning Indicator The aircraft will return to the Home Point automatically and hover at 2 meters above the Low battery Battery power Aircraft status Home Point. Users can also level warning is low.
Page 18 The aircraft cannot avoid obstruction during RTH when the Forward Vision System is disabled. Users can use the remote controller to control aircraft altitude and speed. It is important to set a suitable Failsafe altitude before each flight. Launch the DJI GS RTK app, tap and tap to set the Failsafe Altitude.
Page 19 Users retain control of aircraft flight orientation. 3. If Landing Protection is inactive, the DJI GS RTK app will display a landing prompt when the aircraft descends below 0.3 meters. Tap to confirm or pull down the control stick for 2 seconds to land when the environment is appropriate for landing.
Page 20: Industrial Applications
To plan operations, insert the microSD card with the KML/KMZ files into the microSD card slot on the remote controller to import the files into DJI GS RTK. For files including polygons, users can view the data on the map and use it to plan flight areas. For files including line strings, users can only view the data on the map, but cannot use it for planning.
Page 21 Planning Route 1. Go to the main screen in the DJI GS RTK app, tap Plan, and select Waypoint Flight to enter Planning View. 2. Fly the aircraft to the desired position, and short press the C2 Button on the remote controller once to add a waypoint.
Page 22 1. Power on the remote controller, and then power on the aircraft. 2. Go to the main screen in the DJI GS RTK app, and then tap Fly. 3. Tap in the Camera View for camera settings. Tap on the left, select Plan in the drop-down menu, and then select an operation route.
Page 23 Phantom 4 RTK User Manual Operation Safety Notices Only take off in open areas. The operation will be automatically cancelled if the motors are started before beginning the opera- tion. You will need to recall the operation in the operation list.
Page 24: Vision System And Infrared Sensing System
Phantom 4 RTK User Manual System Data Protection During an operation, the System Data Protection feature enables the DJI GS RTK app to retain vital system data (e.g. operation progress, breakpoint) after the aircraft is powered off for battery replacement. Follow the instructions in Operation Resumption to resume the operation after restarting the aircraft.
Page 25 Calibrating Sensors Vision Systems cameras installed on the aircraft are calibrated on delivery. However these cameras are vulnerable to excessive impact and will require occasional calibration via DJI Assistant 2 for Phantom. Follow the steps below to calibrate the sensors.
Page 26 Phantom 4 RTK User Manual Assisted Braking from Obstacle Sensing Powered by the Obstacle Sensing, the aircraft will now be able to actively brake when obstacles are detected around the aircraft. Note that Obstacle Sensing function works best when lighting is adequate and the obstacle is clearly marked or textured.
Page 27: Rtk Functions
Phantom 4 RTK User Manual RTK Functions The Phantom 4 RTK has a built-in DJI Onboard D-RTK, which provides more accurate data for centimeter- level positioning to improve operation precision when using with the DJI D-RTK 2 High-Precision GNSS Mobile Station or Network RTK service. The onboard D-RTK, providing precision position and speed information combined with optimized algorithms, is more accurate than a standard compass sensor and functions even with magnetic interference from metal structures, ensuring stable flight.
Page 28: Flight Recorder
PC through the Micro USB port and launch the DJI Assistant 2. Attaching and Detaching the Propellers Use only DJI approved propellers with your aircraft. The grey and black ring on the propeller indicate where they should be attached and in which direction whey should spin.
Page 29: Dji Intelligent Flight Battery
Phantom 4 RTK User Manual DJI Intelligent Flight Battery The DJI Intelligent Flight Battery has a capacity of 5870 mAh, a voltage of 15.2 V, and a smart charge/ discharge functionality. It should only be charged using an appropriate DJI approved power adapter and charging hub.
Page 30 Battery voltage should reach the appropriate level when operating environment with temperatures between -10°C and 5°C. 3. End the flight as soon as the DJI GS RTK app displays the “Low Battery Level Warning” in low temperature environments. 4. Keep the battery indoors to warm it before flying in low temperature environments.
Page 31 Phantom 4 RTK User Manual Battery Level Indicators LED1 LED2 LED3 LED4 Battery Level 87.5%~100% 75%~87.5% 62.5%~75% 50%~62.5% 37.5%~50% 25%~37.5% 12.5%~25% 0%~12.5% Charging the Intelligent Flight Battery Air cool the Intelligent Flight Battery after each flight. Allow its temperature to drop to room temperature before charging.
Page 32 Phantom 4 RTK User Manual Using the Power Adapter and Charging Hub for Charging 1. Connecting to a Power Source Connect the power adapter to a power outlet (100-240V, 50/60Hz), then connect the charging bub to the power adapter. Power Outle...
Page 33 DJI does not take any responsibility for damage caused by third-party chargers. If the battery level is above 95%, turn on the battery before charging.
Page 35: Remote Controller
Remote Controller Profile The Phantom 4 RTK remote controller has a transmission range of up to 4.3 mi / 7 km (FCC-compliant version) with controls for camera tilt and photo capture. Built into the remote controller is the latest DJI OcuSync to enhance anti-interference ability for more stable and smoother video downlink.
Page 36 Phantom 4 RTK User Manual Charging the Remote Controller Charge the remote controller Intelligent Battery using the included AC power adapter and Charging Hub. 1. Place the battery into the Charging Hub, connect the AC power adapter to the Charging Hub, and then connect the charger to a power outlet (100-240V, 50/60Hz).
Page 37 Phantom 4 RTK User Manual Controlling the Aircraft This section explains how to control the orientation of the aircraft through the remote controller. Control can be set to Mode 1 , Mode 2 or Mode 3, or to a custom mode.
Page 38 Phantom 4 RTK User Manual Remote Aircraft Controller Remarks Indicates Nose Direction) (Mode 2) Moving the left stick up and down changes the aircraft’s elevation. Push the stick up to ascend and down to descend. When both sticks are centered, the aircraft will hover in place.
Page 39: Remote Controller Status Led
Phantom 4 RTK User Manual RTH Button Press and hold the RTH button to start the Return to Home (RTH) procedure. The LED ring around the RTH Button will blink white to indicate that the aircraft is entering RTH mode. The aircraft will then return to the last recorded Home Point.
Page 40: Linking The Remote Controlle
If using Multi-Aircraft Control function, linking all the aircraft to the same remote controller is required. 1. Power on the remote controller and open the DJI GS RTK app. Power on the aircraft. 2. Tap Fly to enter Camera View and tap >...
Page 41: Multi-Aircraft Control Function
When using the Multi-Aircraft Control function, to avoid interference among operation groups, do not operate more than three groups within a 50-meter radius. Unless using the Phantom 4 RTK with a DJI D-RTK 2 Mobile Station, it is necessary to manually configure each remote controller’s serial number in the DJI GS RTK app.
Page 42 Phantom 4 RTK User Manual Multi-Aircraft Operations 1. Select the desired aircraft by switching control. 2. Tap the status box of the selected aircraft, then tap on the left of the screen, or tap on top of the screen to select and use an operation in the Plan tag. Perform the operation after setting operation parameters.
Page 44: Gimbal And Camera
Profile The Phantom 4 RTK camera uses a 1-inch CMOS sensor with effective pixels of 20 M and a 24 mm (35 mm format equivalent) wide-angle lens. It is equipped with a blue glass filter to deliver enhanced picture quality and a UV lens for additional protection.
Page 45 Photogrammetry and Waypoint Flight operations. Camera Operation Use the Shutter and Video Recording buttons on the remote controller or in the DJI GS RTK app to shoot the photos or videos. Camera Status LED Indicator Descriptions The Camera LED Indicator lights up after the flight battery is powered on.
Page 46: Gimbal
Two gimbal operation modes are available. Switch between the different operation modes on the gimbal settings page of the DJI GS RTK app. Refer to the table below for details: The angle between the gimbal’s orientation and aircraft’s nose remains Follow Mode constant at all times.
Page 48: Dji Gs Rtk App
DJI GS RTK App The DJI GS RTK app is designed for mapping applications. It can be used to plan operation areas and flight routes, set various parameters, and view the status of the operations in real time. Main Screen...
Page 49: Planning View
Phantom 4 RTK User Manual Planning View Photogrammetry Mapping Area Estimated Flight Time Photos/SD Card Photogrammetry Height(M)(GSD 2.74 cm/pixel) Speed (M/s) Finish RETURN-TO-HOME Camera Settings Advanced Settings Cancel Save 1. Main Screen : Tap this icon to return to the main screen.
Page 50 Phantom 4 RTK User Manual Advanced Settings: Includes horizontal overlapping rate, vertical overlapping rate and margin. The vertical overlapping rate indicates the overlapping rate of two pictures captured consecutively along the same path. The horizontal overlapping rate indicates the overlapping rate of two pictures on two parallel paths.
Page 51: Camera View
Phantom 4 RTK User Manual Camera View After tapping Fly in the main screen, users can switch between Camera View and Map View. The descriptions below use the Camera View as an example. In Flight (RTK) 19:29 SHUTTER 0.3 Auto 10米...
Page 52 Phantom 4 RTK User Manual 6. Control and HD Video Link Signal Strength : Shows the signal strength of the control and HD video downlink connection between the aircraft and the remote controller. 7. Obstacle Sensing Function Status : Tap into this button to enable or disable features provided by the Vision System.
Page 53 Phantom 4 RTK User Manual 17. Flight Parameters : Vertical distance from the aircraft o the Home Point. : Horizontal distance from the aircraft to the Home Point. : Movement speed across a vertical distance. : Movement speed across a horizontal distance.
Page 55: Flight
DJI GS RTK app. The locations designated by GEO are called GEO Zones. GEO Zones are specific flight areas that are categorized by flight regulations and restrictions. GEO Zones that prohibit flight are implemented around locations such as airports, power plants, and prisons.
Page 56: Flight Restrictions
Restricted Zone, please go to https://www.dji.com/flysafe or contact flysafe@dji.com to unlock the zone. DJI GEO Zones aim to ensure the user’s flight safety, but it cannot be guaranteed to be in full compliance with local laws and regulations. Users should check local laws, regulations, and regulatory requirements before each flight and are responsible for the flight safety.
Page 57 Phantom 4 RTK User Manual Maximum Flight Altitude Max Radius Home Point Height of aircraft when turned on Strong GNSS Signal Restriction Description DJI GS RTK App Message Maximum Flight Altitude reached. Adjust Aircraft's altitude cannot exceed Max Altitude your altitude using Aircraft Settings if the specified value.
Page 58: Geo Unlocking
Self-Unlocking is used for Authorization Zones, where the user is required to submit an unlock re- quest by authenticating their phone number for a registered DJI account. This feature is only avail- able in certain countries. Users can choose whether to submit their unlock request via the website at https://www.dji.com/flysafe (Scheduled Self-Unlocking), or through the DJI GS RTK app (Live...
Page 59: Preflight Checklist
7. Ensure that the sensors for the Vision System and Infrared Sensing System are clean. Calibrating the Compass Only calibrate the compass when the DJI GS RTK app or the status indicator prompt you to do so. Observe the following rules when calibrating your compass: DO NOT calibrate your compass where there is a chance of strong magnetic interference, such as magnetite, parking structures, and steel reinforcements underground.
Page 60: Starting/Stopping The Motors
Phantom 4 RTK User Manual 4. Re-calibrate the aircraft if the aircraft status indicators glows blinking red. If the Aircraft Status Indicator blinks red and yellow after the calibration procedure, move your aircraft to a different location and try again.
Page 61: Flight Test
2. Turn on the remote controller and then turn on the Intelligent Flight Battery. 3. Launch the DJI GS RTK app and tap Fly. 4. Wait until the Aircraft Status Indicators start to blink green slowly, which indicates that GNSS or RTK is in use.
Page 63: Dji Assistant 2 For Phantom
DJI Assistant 2 for Phantom Update firmware, copy flight records and calibrate the Vision System in the DJI Assistant 2 for Phantom software. For users that own DJI Agras aircraft, the DJI Assistant 2 for MG can also be used for the functions above.
Page 66 Phantom 4 RTK User Manual Frequency Used GPS: L1/L2; GLONASS: L1/L2; BeiDou: B1/B2; Galileo*: E1/E5 Multi-Frequency Multi- First-Fixed Time: < 50 s System High-Precision Positioning Accuracy: Vertical 1.5 cm + 1 ppm (RMS); Horizontal 1 cm + 1 ppm RTK GNSS (RMS).
Page 67 Phantom 4 RTK User Manual FOV (Field of View) 84°, 8.8 mm (35 mm format equivalent: 24 mm), f/2.8 - f/11, Lens auto focus at 1 m - ∞ Video: 100 - 3200 (Auto), 100 - 6400 (Manual) ISO Range...
Page 68: Updating The Firmware
2. Connect the USB-C port on the remote controller to the Micro USB port on the aircraft via a USB-C OTG cable and a Micro USB cable. 3. There will be a prompt on the lower right corner in the DJI GS RTK app if there is new firmware. Tap the text to enter firmware page.
Page 69 This content is subject to change. Download the latest version from http://www.dji.com/phantom-4-rtk If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. PHANTOM is a trademark of DJI. Copyright © 2018 DJI All Rights Reserved.
