- Page 1 SIP Contemporary Trimstyle Hotel Telephone User Guide (US version) Models: SIP contemporary trimstyle 1-line hotel telephone - CTM-S2312 SIP contemporary trimstyle 2-line hotel telephone - CTM-S2322...
- Page 2 Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: This product should be installed by a qualified technician. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS).
- Page 3 Ne surchargez pas les prises de courant ni les rallonges électriques, car ceci peut constituer un risque d’incendie ou d’électrocution. Débranchez cet appareil de la prise de courant et communiquez avec le département de service à la clientèle de VTech dans les cas suivants: Lorsque le cordon d’alimentation est endommagé...
-
Page 4: Table Of Contents
Installation option - desktop position .....................4 Installation option - converting from desktop to wall mount position ..........5 Telephone settings ........................6 Telephone operation ........................7 SIP contemporary trimstyle 1-line - CTM-S2312 ................7 SIP contemporary trimstyle 2-line - CTM-S2322 ................8 Appendix ............................9 Troubleshooting ..........................9 VTech Hospitality limited warranty program ................10... -
Page 5: Parts Checklist
Parts checklist Items contained in the respective telephone package: Model name Model number Parts included SIP contemporary CTM-S2312 trimstyle 1-line Telephone base Wall mount bracket Corded handset Cat-5 network cables (2) SIP contemporary CTM-S2322 trimstyle 2-line Telephone base Wall mount bracket... -
Page 6: Telephone Layout
Telephone layout SIP contemporary trimstyle 1-line - CTM-S2312 -/VOLUME/+ MESSAGE WAITING LED TALK HOLD FLASH SPEAKER MUTE MESSAGES SPEED DIAL KEYS POWER LED Wall mount clip... -
Page 7: Sip Contemporary Trimstyle 2-Line - Ctm-S2322
Telephone layout SIP contemporary trimstyle 2-line - CTM-S2322 -/VOLUME/+ MESSAGE WAITING LED LINE 2 CONF LINE 1 HOLD FLASH SPEAKER MUTE MESSAGES SPEED DIAL KEYS POWER LED Wall mount clip... -
Page 8: Installation
• For CTM-S2312: (1) LED 1 and LED 2 turn on and then go off. (2) LED 1 flashes. (3) The LED 1 stops flashing and then the LED 2 flashes. (4) LED 1, LED 2, and LED 3 illuminate for 500ms when initialization and system registration are successful. -
Page 9: Installation Option - Converting From Desktop To Wall Mount Position
Installation Installation option - converting from desktop to wall mount position Unplug the Cat-5 network cable from the network wall jack. Put the handset aside. On the telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. -
Page 10: Telephone Settings
Telephone settings All telephone settings are programmed through the administrative web portal. Please refer to the SIP Phone Configuration Guide for details. -
Page 11: Telephone Operation
Telephone operation SIP contemporary trimstyle 1-line - CTM-S2312 Receive a call When there is an incoming call, the telephone rings and the TALK key flashes. To answer a call: Press TALK or . The TALK key illuminates when the phone line is in use. The key illuminates when in speakerphone mode. -
Page 12: Sip Contemporary Trimstyle 2-Line - Ctm-S2322
Telephone operation SIP contemporary trimstyle 2-line - CTM-S2322 Receive a call When there is an incoming call, the telephone rings and the corresponding line key flashes. To answer a call: Press the flashing line key, or press to pick up the ringing line. The respective line key illuminates when the phone line is in use. key illuminates when in speakerphone mode. -
Page 13: Appendix
Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. For customer service, visit our website at www.vtechhotelphones.com or contact your local distributor. The telephone does not work at all. • Make sure the Cat-5 network cable is plugged into the LAN port of the telephone base and the network wall jack with Power over Ethernet (PoE). -
Page 14: Vtech Hospitality Limited Warranty Program
If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair and return shipping costs for the repair of Products that not covered by this limited warranty. -
Page 15: Important Note
Appendix Important note This equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made for access to emergency services. Environmental notes • Do not expose to direct sunlight. • This is normal that the cordless handset may become warm when the batteries are being charged or being used for a long period of time. -
Page 16: Fcc, Acta And Ic Regulations
For repair procedures, follow the instructions outlined under VTech Hospitality limited warranty program in the user’s manual. If this equipment is causing harm to the telephone network, your telephone service provider may temporarily discontinue your telephone service. -
Page 17: Maintenance
Appendix Maintenance Taking care of your telephone Your telephone contains sophisticated electronic parts, so it must be treated with care. Avoid rough treatment Place the handset down gently. Save the original packing materials to protect your telephone if you ever need to ship it. Avoid water Your telephone can be damaged if it gets wet. -
Page 18: Technical Specifications
Appendix Technical specifications SIP classic trimstyle 1-line/2-line - CTM-S2312/S2322 Power requirement PoE class 2 powered (48V) Frequency control Crystal controlled PLL synthesizer Transmit frequency 1921.536 - 1928.448MHz Channels Nominal effective range Actual operating range may vary according to environmental conditions at the time of use. -
Page 19: Index
Index Answer a call 7 Volume 7 VTech Hospitality limited warranty program 10 Call waiting 7 Checklist 1–3 Wall mount 4–5 Warranty 10 Disposal instructions 11 End a call 7 Environmental notes 11 Flash 7 Hold 7 Important safety instructions i... - Page 20 VTECH TELECOMMUNICATIONS LTD. A member of THE VTECH GROUP OF COMPANIES. VTech is the registered trademark of VTech Holdings Limited. Petite™ Phone is a trademark of VTech Communications, Inc. Copyright © 2018 for VTech Communications Inc. All rights reserved. Printed in China. Version 2. 03/18.
