- Page 1 SIP Contemporary Series CTM-S2115 SIP 1-Line Hidden Base with Cordless Handset and Charger User ‘s Guide...
-
Page 2: Important Safety Instructions
Important safety instructions When using your telephone equipment, basic safety precautions should always followed to reduce the risk of fire, electric shock and injury, including the following: 1. This product should be installed by a 10. Do not allow anything to rest on the qualified technician. - Page 3 • If the product has been dropped and 20. In wall mounting position, make sure the telephone base and/or handset has to mount the telephone base on the been damaged. wall by aligning the eyelets with the mounting studs of the wall plate. Then •...
- Page 4 • Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; • Extremely low air pressure that can result in an explosion or the leakage of flammable liquid or gas.
-
Page 5: Table Of Contents
Telephone layout ....... 7 Disclaimer and Limitation of Liability.....26 SIP 1-Line Hidden Base with Cordless European Directives ..........26 Handset and Charger - CTM-S2115 ....7 Declaration of Conformity ........26 Installation .......... 9 Disposal of batteries and product ....27 SIP 1-Line Hidden Base with Cordless Technical specifications .... -
Page 6: Parts Check List
S211X BASE Artwork illustration scale 40% RESET SIP 1-Line Hidden Base with Cordless CTM-S2115 Handset and Charger PART DESCRIPTION COLOR/MATERIAL TEXTURE/FINISH 01. Left Housing Graphite Spray SPI B-1 Silkscreen on the Top ( ) - Pantone 8001C 02. -
Page 7: Telephone Layout
Telephone layout SIP 1-Line Hidden Base with Cordless Handset and Charger - CTM-S2115 Handset FLASH/TALK Handset Charger Numeric dial keys SPEAKER Speed dial keys Programmable key #1 Programmable key #2 Handset earpiece VOLUME +/- EMERGENCY HOLD MUTE MESSAGES Low Battery LED... - Page 8 S211X BASE Artwork S211X BASE Artwork Base Station Layout Base Station RESET FIND HANDSET button. • Short press (for less than 2 seconds) to find the handset by making it ring. FIND HANDSET button. Short press again to stop handset ringing. POWER LED •...
-
Page 9: Installation
(PoE Class 2) from your network. If you are IMPORTANT INFORMATION not using PoE, install the base station near a 1. Use only a compatible VTech power power outlet not controlled by a wall switch. adapter. To order a replacement power... - Page 10 4. Check to make sure the plate is secure at To mount the base station on the wall top and bottom. It should be flush with the 1. Install two mounting screws on the wall. base station body. Choose screws with heads larger than 5.
-
Page 11: Handset Charger Installation
Handset Charger Installation Installation Notes 1. Install the handset charger as shown Avoid placing the base station, handset, or below. handset charger too close to: • Make sure the supplied power adapter • Communication devices such as is securely plugged into an outlet not television sets, DVD players, or other controlled by a wall switch. -
Page 12: Handset Registration
Handset Registration Your cordless handset is preregistered to the base station. You do not need to register your cordless handset. You can register additional cordless handsets to the base station. The Base station accommodates up to four CTM-C4402 cordless handsets. 1. -
Page 13: Handset Battery Charging
Handset battery charging 3. Plug the battery connector securely into the socket inside the handset battery The battery must be fully charged before compartment. Place the battery with the using the cordless handset for the first time. label THIS SIDE UP facing up and the The CHARGE LED turns on when the cordless wires inside the battery compartment. -
Page 14: Set Up
Set up SIP 1-Line Hidden Base with Cordless Handset and Charger - CTM-S2115 Default settings are indicated by asterisks (*). Setting Options Adjustable by Listening volume- Handset 1, 2, 3, 4, 5, 6*, 7, 8 User and administrator Ringer tone... -
Page 15: Voice Menu
Voice Menu The Voice menu enables you to use the handset to query and change phone settings. To access the Voice Menu: 1. When the phone is idle, press this key sequence on the handset: TALK Û Û Û Û. A digitied voice on the handset will announce Voice Menu options. -
Page 16: Operation
Share a call SIP 1-Line Hidden Base with Cordless A maximum of two cordless handsets can be used at the same time on an external Handset and Charger - CTM-S2115 call. Using the cordless handset Join a call When the cordless handset is in use, the... -
Page 17: Call Waiting
Call waiting 1. When you hear a call waiting tone during a call, press FLASH/TALK on the cordless handset to put the current call on hold and take the new incoming call. 2. Press FLASH/TALK at any time to switch back and forth between calls. -
Page 18: Appendix
Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. For customer service, call +44 (0)1706 694 070 or email ukca@trustdistribution.com. For cordless telephone Question Suggestions • Make sure the Cat-5 network cable is plugged into the NET port of the base station and the network wall jack with Power over Ethernet (PoE). - Page 19 Question Suggestions • Try all the above suggestions. • The Cat-5 network cable may be defective. Install a new Cat-5 network cable. • Make sure your network is providing Power over Ethernet (PoE). • Disconnect the base station from the network wall jack and connect a different working SIP telephone.
- Page 20 Question Suggestions • Make sure your network is providing Power over Ethernet (PoE). • Make sure the initialisation and system registration process completes (page 12). The telephone cannot register to the SIP • Disconnect the Cat-5 network cable network server. from the network wall jack and connect it back into the network wall jack with Power over Ethernet (PoE) to start the...
- Page 21 Question Suggestions • Make sure the Cat-5 network cable is plugged into the NET port of the base station and the network wall jack with Power over Ethernet (PoE). • The cordless handset may be too far from the base station. Move it closer to the base station.
- Page 22 Question Suggestions • Make sure the Cat-5 network cable is plugged into the LAN port of the base station and the network wall jack with Power over Ethernet (PoE). • Check your SIP server or telephone administrative settings. Refer to the SIP Phone Configuration Guide for details.
- Page 23 Question Suggestions • Make sure the Cat-5 network cable is plugged in correctly and securely. I hear noise on the cordless handset and the • Unplug the Cat-5 network cable. Wait keys do not work. for 15 seconds before plugging it back •...
-
Page 24: Vtech Hospitality Limited Warranty Program
During the limited warranty period, VTech’s authorised service representative will repair or replace, at VTech’s option, without charge, a Product that is not free from defects in materials and workmanship. If VTech’s authorised service representative repairs the Product, new or refurbished replacement parts may be used. - Page 25 If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorise the cost of repair and return shipping costs for the repair of Products that not covered by this limited warranty.
-
Page 26: Maintenance
Avoid rough treatment arise through the use of this product. VTech Place the handset down gently. Save the Communications, Inc. and its suppliers original packing materials to protect your assume no responsibility for any damage or telephone if you ever need to ship it. -
Page 27: Disposal Of Batteries And Product
Disposal of batteries and product ‚) ( Product disposal instructions for These symbols on the products, business users packaging, and/or accompanying documents mean that used electrical and electronic If you wish to discard electrical and electronic products and batteries must not be mixed equipment, please contact your dealer or with general household waste. -
Page 28: Technical Specifications
Technical specifications SIP 1-Line Hidden Base with Cordless Handset and Charger - CTM-S2115 Frequency control Crystal controlled PLL synthesiser Transmit frequency Handset: 1881.792-1897.344 MHz (European Union and Base Station: 1881.792-1897.344 MHz United Kingdom) Channels Nominal effective range Actual operating range may vary according to environmental conditions at the time of use. - Page 29 Index Limited Warranty 24 Listening volume 14, 16 Answer a call 16 Messages 17 Message Waiting LED 17 Battery 13, 18, 20, 21, 23, 26, 27, 28 Mute 16 Battery charging 13 Place a call 16 Call waiting 17 Receive a call 16 Deregistration, Handset 12 Registration, Handset 12 Ringer tone 14...
- Page 30 Specifications are subject to change without notice. Copyright © 2021 VTech Telecommunications, Inc. All rights reserved. 02/21. CTM-S2115_UG_V1_CEC_EU-UK_20210221...
