- Page 1 ES300 Instructions for use Instructions for Use Original Instructions Kullanim Talimatlari Instruc iuni de utilizare A-English 9/2015 revised 8/2016 REV B B-Türkçe Form no. 56091180 D-Românesc Model: 56265503...
-
Page 3: Table Of Contents
Nameplate ..................A-3 Uncrating the Machine ..............A-3 Cautions and Warnings ..............A-4 Grounding Instructions ..............A-5 Know Your Machine – ES300 ..........A-6 – A-7 Know Your Control Panel............. A-8 Preparing the Machine for Use Filling the Solution Tank ..............A-9 Before Using ................... -
Page 4: Introduction
When the machine is delivered, carefully inspect the shipping carton and the machine for damage. If damage is evident, save the shipping carton so that it can be inspected. Contact the Nil sk Customer Service Department immediately to le a freight damage claim. 9/2015 56091180 - ES300 A - 3... - Page 5 Liquid ejected at the spray nozzle could be dangerous as a result of its temperature, pressure or chemical content. • Only use the brushes provided with the appliance or those speci ed in the instruction manual. The use of other brushes may impair safety. SAVE THESE INSTRUCTIONS A - 4 ES300 - 56091180 9/2015...
-
Page 6: Grounding Instructions
15 M (50 ft) long. WARNING! • If an extension cord is used, the plug and socket must be of watertight construction. • Inadequate extension cords can be dangerous. 9/2015 56091180 - ES300 A - 5... - Page 7 A - ENGLISH INSTRUCTIONS FOR USE KNOW YOUR MACHINE – ES300 Solution Switch Brush Storage Lift Lever Power Cord Vacuum Shoe Release Lever Vacuum Mode Selector Knob Vacuum Shoe Vacuum Shoe Mode Solution Filter Accessory Mode Recovery Tank Automatic Float Shut-Off...
-
Page 8: Know Your Machine - Es300
INSTRUCTIONS FOR USE ENGLISH - A KNOW YOUR MACHINE – ES300 Accessory Solution Port Control Panel Hand Tool (Optional) Recovery Tank Handle Solution Drain Hose / Level Indicator Accessory Vacuum Hose Port Handle Assembly 9/2015 56091180 - ES300 A - 7... -
Page 9: Know Your Control Panel
A - ENGLISH INSTRUCTIONS FOR USE KNOW YOUR CONTROL PANEL Main Power Switch Circuit Breaker 5 Amp Vacuum Shoe / Accessory Switch A - 8 ES300 - 56091180 9/2015... -
Page 10: Preparing The Machine For Use
PLAN FOR CLEANING Before you begin extracting, look at the area to be cleaned and plan your work. Divide the space into sections. Overlap each pass 2 inches (5 cm). 9/2015 56091180 - ES300 A - 9... -
Page 11: Operating The Machine
Press the Vacuum Shoe / Accessory Switch (27) to the accessory position. Press the Main Power Switch (24) to the On (I) position to activate the vacuum motor and solution pump. See your Nil sk Distributor for accessories that may be used with the ES300. A - 10... -
Page 12: Hard Floor Kits
Release Lever (D) and slide the squeegee tool into place. NOTE: Hard fl oor applications can require the use of a different brush. Brush selector guide and part numbers can be found in the Parts List. 9/2015 56091180 - ES300 A - 11... -
Page 13: After Using The Machine
Check the vacuum shoe daily. Remove any built-up string, hair or carpet bers. See Figure 7. Push and hold in the Vacuum Shoe Release Lever (8) and slide the Vacuum Shoe (9) off of its mounting pin. Then disconnect the recovery hose from the vacuum shoe. FIGURE 7 A - 12 ES300 - 56091180 9/2015... -
Page 14: Spray Nozzle Maintenance
Grab the brush at the end with the Brush Retainer Clip (C) and pull straight out. Install a new brush at the drive lug end rst then push in the other brush end in until it snaps into the retainer clip. FIGURE 8 9/2015 56091180 - ES300 A - 13... -
Page 15: Troubleshooting
Solution tank empty ( ll solution tank) Solution lines or solution lter clogged ( ush lines and lter) Solution line not connected to lter assembly (connect solution line) Spray nozzle is plugged (clean spray nozzle) A - 14 ES300 - 56091180 9/2015... -
Page 16: Accessories / Options
Material Composition and Recyclability Type % of machine weight % recyclable Aluminum 100% Electrical / motors / engines - misc Ferrous metals 100% Harnesses / cables Liquids Plastic - non-recyclable Plastic - recyclable 100% Polyethylene Rubber 9/2015 56091180 - ES300 A - 15...
