F263 Series Liquid Level Switches
Installation Instructions
Applications
IMPORTANT: Use this F263 Series Liquid Level Switch only as an operating control. Where failure or
malfunction of the liquid level switch could lead to personal injury or property damage to the controlled equipment
or other property, additional precautions must be designed into the control system. Incorporate and maintain other
devices, such as supervisory or alarm systems or safety or limit controls, intended to warn of or protect against
failure or malfunction of the liquid level switch.
IMPORTANT : Utiliser ce F263 Series Liquid Level Switch uniquement en tant que dispositif de régulation.
Lorsqu'une défaillance ou un dysfonctionnement du liquid level switch risque de provoquer des blessures ou
d'endommager l'équipement contrôlé ou un autre équipement, la conception du système de contrôle doit
intégrer des dispositifs de protection supplémentaires. Veiller dans ce cas à intégrer de façon permanente
d'autres dispositifs, tels que des systèmes de supervision ou d'alarme, ou des dispositifs de sécurité ou de
limitation, ayant une fonction d'avertissement ou de protection en cas de défaillance ou de dysfonctionnement
du liquid level switch.
IMPORTANT: Do not use F263MAC and F263MAP Liquid Level Switches where the fluid in the pipes drops
below the fluid's freezing point, causing an internal freeze-up.
IMPORTANT: Do not use F263 Series Liquid Level Switches with hazardous fluids or in hazardous
atmospheres. Use in these conditions may cause malfunction or improper operation.
This product is made of a copper alloy, which contains lead. The product is therefore not to be used on drinking
water.
The F263 Series Liquid Level Switches are designed to maintain a liquid level in indoor or outdoor closed tanks
holding water or other non-corrosive liquids. When the liquid level in the tank rises above or falls below the required
level, the SPDT switch closes one circuit and opens a second circuit.
Use F263 Series Liquid Level Switches in closed tanks where a liquid level is to be maintained. A change in the
liquid level opens or closes an electrical circuit.
Use F263MAP switches on indoor or outdoor tanks that hold water or other nonhazardous liquids at temperatures
greater than the liquid's freezing point and between -20°F (-29°C) and 212°F (100°C). The maximum allowable
liquid pressure is 150 psig
(1035 kPa).
Use F263MAC switches on indoor or outdoor tanks that hold water or other nonhazardous liquids at temperatures
greater than the liquid's freezing point and between -20°F (-29°C) and 250°F (121°C). The maximum allowable
liquid pressure is 100 psig (690 kPa).
Note: Do not use these liquid level switches with liquids with a density less than the density of water.
Refer to the
F263 Series Liquid Level Switches Installation Instructions
Part No. 24-7664-2985, Rev. D
QuickLIT website
for the most up-to-date version of this document.
1
Issued August 2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Penn F263 Series
Summary of Contents for Penn F263 Series
-
Page 1: Installation Instructions
SPDT switch closes one circuit and opens a second circuit. Use F263 Series Liquid Level Switches in closed tanks where a liquid level is to be maintained. A change in the liquid level opens or closes an electrical circuit. -
Page 2: Installation Procedure
IMPORTANT: Do not remove the cover gasket or the wire grommet in the conduit opening. Removing these items will allow moisture to enter and condensate to form inside a NEMA 3R enclosure. F263 Series Liquid Level Switches Installation Instructions... -
Page 3: Color-Coded Screw Terminals
Do not exceed the flow switch’s electrical ratings. Color-Coded Screw Terminals IMPORTANT: Use the terminal screws provided (8-32 x 1/4 in. binder head). Substitution of other screws voids the warranty and agency approvals. F263 Series Liquid Level Switches Installation Instructions... - Page 4 See Figure 4 and Figure 5 for suggested circuits for controlling liquid levels with several inches (or feet) between minimum and maximum levels. Pump In Pump High Level F263 Switch Low Level F263 Switch Figure 4: Circuit for Controlling Fill Levels F263 Series Liquid Level Switches Installation Instructions...
-
Page 5: Setup And Adjustments
When the liquid level falls approximately 1/2 in. (13mm) below the height at which the switch is installed, the switch closes the red contact (common) to the blue contact. See Figure 6 and Figure 7. F263 Series Liquid Level Switches Installation Instructions... -
Page 6: Repair Information
Figure 6: F263 Float Switch Setup Repair Information Do not make field repairs, except for replacement of the float. For a replacement control or float, contact the nearest Johnson Controls/PENN distributor. For more information, contact Johnson Controls/PENN application engineering at 1-800-275-5676. Technical Specifications... -
Page 7: F263 Series Liquid Level Float Switches
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult Johnson Controls/PENN Refrigeration Application Engineering at 1-800-275-5676. Johnson Controls shall not be liable for damages resulting from misapplication or misuse of its products. - Page 8 CHINA www.penncontrols.com ® Johnson Controls and PENN are registered trademarks of Johnson Controls in the United States of America and/or other countries. All other trademarks used herein are the property of their respective owners. © Copyright 2018 by Johnson Controls. All rights reserved.
