- Page 1 User Manual Installation Industrial Access-Point / Client / Access-Bridge BAT867-R Installation BAT867-R Technical support Release 06 08/2018 https://hirschmann-support.belden.com...
- Page 2 In addition, we refer to the conditions of use specified in the license contract. You can get the latest version of this manual on the Internet at the Hirschmann product site (www.hirschmann.com). Hirschmann Automation and Control GmbH Stuttgarter Str.
-
Page 3: Table Of Contents
Connecting the terminal blocks Operating the device 2.5.1 Connecting the power supply through a terminal block Connecting data cables 2.6.1 10/100/1000 Mbit/s twisted pair port Making basic settings Obtain compliance for operation in the European Union Installation BAT867-R Release 06 08/2018... - Page 4 8.5.1 IEEE 802.11b 8.5.2 IEEE 802.11g 8.5.3 IEEE 802.11a 8.5.4 IEEE 802.11n 8.5.5 IEEE 802.11ac EMC and immunity Network range Power consumption/power output Scope of delivery, order numbers and accessories Underlying technical standards Further support Installation BAT867-R Release 06 08/2018...
-
Page 5: Safety Instructions
Certified usage Use the product only for the application cases described in the Hirschmann product information, including this manual. Operate the product only according to the technical specifications. See “Technical data” on page 35. Connect to the product only components suitable for the requirements of the specific application case. - Page 6 WLAN device with regard to the general operating permission and the maximum emission levels. Install and operate this equipment with a minimum distance of 19.7 inches (50 cm) between the antenna and your body. Installation BAT867-R Release 06 08/2018...
- Page 7 The voltage connected complies with the requirements for a safety extra-low voltage (SELV) as per IEC/EN 60950-1. Relevant for North America: Exclusively use 60/75 °C (140/167 °F) or 75 °C (167 °F) copper (Cu) wire. Table 1: Requirements for connecting electrical wires Installation BAT867-R Release 06 08/2018...
- Page 8 The power supply cable is suitable for the voltage, the current and the physical load. Hirschmann recommends a wire diameter of 0.5 mm² to 0.75 mm² (AWG20 up to AWG18). The cross-section of the ground conductor is the same size as or bigger than the cross-section of the power supply cables.
- Page 9 In accordance with the above-named EU directive(s), the EU conformity declaration will be available to the relevant authorities at the following address: Hirschmann Automation and Control GmbH Stuttgarter Str. 45-51 72654 Neckartenzlingen Germany The product can be used in living areas (living area, place of business, small business) and in industrial areas.
- Page 10 5 GHz band channels. Compliant operation of the device is achieved by an unchangeable determination of the country setting. To obtain RED compliance, perform the work steps described in chapter “Obtain compliance for operation in the European Union” on page Installation BAT867-R Release 06 08/2018...
- Page 11 Name and website of the competent authority: Commission for Communications Regulation www.comreg.ie United Kingdom (UK): Frequency range: 5725 MHz to 5850 MHz Condition: Light-licensing regime Name and website of the competent authority: Ofcom www.ofcom.org.uk Installation BAT867-R Release 06 08/2018...
- Page 12 Note for the use in the USA and in Canada The following section applies to BAT867-R variants with the characteristic value US (USA/Canada) for country approvals which are labeled as...
- Page 13 This transmitter is restricted to indoor use only within the 5.15 to 5.25 GHz band to reduce potential for harmful interference to co-channel mobile satellite systems. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that permitted for successful communication.
-
Page 14: About This Manual
About this manual The “Installation” user manual contains a device description, safety instructions, a description of the display, and the other information that you need to install the device. Installation BAT867-R Release 06 08/2018... -
Page 15: Key
The symbols used in this manual have the following meanings: Listing Work step Subheading Installation BAT867-R Release 06 08/2018... -
Page 16: Description
The devices allow you to install a new LAN or expand an existing LAN. Thanks to their high level of flexibility, the BAT867-R device is suitable for a wide range of applications. Anywhere that high bandwidths, stable operation and network security is required, WLAN with these devices provides the ideal solution. -
Page 17: Device Name And Product Code
The devices provide you with a large range of functions, which the manuals for the operating software inform you about. You can download these manuals as PDF files from the Internet on the Hirschmann product pages (www.hirschmann.com). The Hirschmann network components help you ensure continuous communication across all levels of the company. -
Page 18: Device View
Antenna connection 2 RJ45 socket for 10/100/1000 Mbit/s Twisted Pair connections Power supply A 2-pin terminal block is available to supply the device with power. Further information: See “Connecting the terminal blocks” on page 24. Installation BAT867-R Release 06 08/2018... -
Page 19: 10/100/1000 Mbit/S Twisted Pair Port
10/100 Mbit/s 1000 Mbit/s MDI mode BI_DA+ TX− BI_DA− BI_DB+ — BI_DC+ — BI_DC− RX− BI_DB− — BI_DD+ — BI_DD− MDI-X mode BI_DB+ RX− BI_DB− BI_DA+ — BI_DD+ — BI_DD− TX− BI_DA− — BI_DC+ — BI_DC− Installation BAT867-R Release 06 08/2018... -
Page 20: Connections For Antennas
The "Antenna Guide" document provides an overview of the antennas that can be used as well as the suitable antenna accessories. This document is available for download as a PDF file on the Hirschmann product pages (www.hirschmann.com). Display elements After the supply voltage is set up, the software starts and initializes itself. -
Page 21: Reset Button
Ethernet connection active yellow flashing Data traffic Reset button The device has a reset button. You will find more information in the “User Manual Configuration Guide”, in the chapter “Using the Boot Configurations”. Installation BAT867-R Release 06 08/2018... -
Page 22: Installation
Verify that the device maintains the minimum clearing in order to meet the climatic conditions: Top and bottom sides of device: 1.97 in (5 cm) Left and right device side: 0.79 in (2 cm) Installation BAT867-R Release 06 08/2018... -
Page 23: Grounding The Device
0.5 mm² (AWG20). Proceed as follows: Ground the device via the functional earth screw. The functional earth screw is located on the topside as shown in the illustration. Installation BAT867-R Release 06 08/2018... -
Page 24: Installing The Antennas
Failure to follow this instruction can result in death, serious injury, or equipment damage. Note: The supply voltage is connected to the device casing through protective elements exclusively. Installation BAT867-R Release 06 08/2018... -
Page 25: Operating The Device
See “Requirements for connecting electrical wires” on page 7. See “Requirements for connecting the supply voltage” on page 8. Failure to follow this instruction can result in death, serious injury, or equipment damage. Installation BAT867-R Release 06 08/2018... -
Page 26: Connecting The Power Supply Through A Terminal Block
Mount the terminal block on the device using screws. Enable the supply voltage. Connecting data cables 2.6.1 10/100/1000 Mbit/s twisted pair port Further information: See “10/100/1000 Mbit/s twisted pair port” on page 19. Connect the data cables according to your requirements. Installation BAT867-R Release 06 08/2018... -
Page 27: Making Basic Settings
Entry via the HiDiscovery protocol in the applications HiDiscovery or Industrial HiVision Configuration via BOOTP You will find more information in the “User Manual Configuration Guide”. This document is available for download as a PDF file on the Hirschmann product pages (www.hirschmann.com). Installation BAT867-R Release 06 08/2018... -
Page 28: Obtain Compliance For Operation In The European Union
Make the country setting unchangeable using the Command Line Interface (CLI), the graphical user interface or the LANconfig software. You can download the LANconfig software as an ISO image from the Hirschmann product pages (www.hirschmann.com). Perform the following work steps: Command Line Interface (CLI) ... - Page 29 Specific country settings such as “France” or “Germany” include additional country specific channels in comparison to the “Europe” country setting. The device ignores specific country settings and uses the country setting “Europe” until the RED compliance has been obtained. Installation BAT867-R Release 06 08/2018...
- Page 30 Note: To check the country setting and correct it, click the “No” button. Then open the Configuration > Wireless LAN > General dialog. To obtain RED compliance, click the “Yes” button. This makes the country setting unchangeable. Subsequently, the device restarts. Installation BAT867-R Release 06 08/2018...
-
Page 31: Configuring The Transmit Power
Note: The operator of a WLAN radio installation must adhere to the applicable transmission threshold values. Use the graphical user interface or the LANconfig software. You can download the LANconfig software as an ISO image from the Hirschmann product pages (www.hirschmann.com). In the graphical user interface, proceed as follows: ... - Page 32 Subtract the cable and installed overvoltage protector attenuation from the antenna gain. Enter the calculated value in the “Antenna gain” field. To save the value, click the “Send” button. Installation BAT867-R Release 06 08/2018...
-
Page 33: Maintenance And Service
Hirschmann is continually working on improving and developing their software. Check regularly whether there is an updated version of the software that provides you with additional benefits. You find information and software downloads on the Hirschmann product pages on the Internet (http://www.hirschmann.com). ... -
Page 34: Disassembly
Disconnect the grounding. Insert a screwdriver horizontally below the housing into the locking gate. Pull the locking gate down without tilting the screwdriver. Lift the bottom of the device away from the DIN rail. Installation BAT867-R Release 06 08/2018... -
Page 35: Technical Data
1060 hPa (−1312 ft; −400 m) Pollution degree Protection classes Degree of protection IP40 a. Temperature of the ambient air at a distance of 2 in (5 cm) from the device b. for DIN rail mounting Installation BAT867-R Release 06 08/2018... -
Page 36: Dimension Drawings
Dimension drawings inch 1.22 49,4 1.94 118,2 4.65 113,1 4.45 117,3 4.62 122,5 4.82 Installation BAT867-R Release 06 08/2018... -
Page 37: Radio Technology
DSSS/CCK Radio topology WLAN Access-Point, Bridge-, Router-, Point-to-Point-, Client-, Client- Bridge-Mode Roaming IEEE 802.11F (Inter-Access Point Protocol) IEEE 802.11r (Fast Roaming) PMK caching Pre authentification OKC (Opportunistic key caching) Installation BAT867-R Release 06 08/2018... -
Page 38: Receiving Sensitivity, Transmit Power And Data Rate
24 dBm −88 dBm 36 Mbit/s 23 dBm −85 dBm 48 Mbit/s 22 dBm −81 dBm 54 Mbit/s 21 dBm −80 dBm Table 6: IEEE 802.11g, frequency range 2.412 GHz to 2.472 GHz, bandwidth 20 MHz Installation BAT867-R Release 06 08/2018... -
Page 39: Ieee 802.11A
Coding Transmit power Receiving sensitivity MCS 0 / 8 23 dBm −92 dBm MCS 1 / 9 23 dBm −88 dBm Table 9: IEEE 802.11n, frequency range 2.412 GHz to 2.472 GHz, bandwidth 40 MHz Installation BAT867-R Release 06 08/2018... - Page 40 MCS 2 / 10 21 dBm −85 dBm MCS 3 / 11 20 dBm −82 dBm MCS 4 / 12 20 dBm −79 dBm Table 11: IEEE 802.11n, frequency range 5.180 GHz to 5.825 GHz, bandwidth 40 MHz Installation BAT867-R Release 06 08/2018...
-
Page 41: Ieee 802.11Ac
21 dBm −88 dBm MCS 2 21 dBm −85 dBm MCS 3 20 dBm −82 dBm MCS 4 20 dBm −79 dBm Table 13: IEEE 802.11ac, frequency range 5.180 GHz to 5.825 GHz, bandwidth 40 MHz Installation BAT867-R Release 06 08/2018... -
Page 42: Emc And Immunity
16 dBm −65 dBm Table 14: IEEE 802.11ac, frequency range 5.180 GHz to 5.825 GHz, bandwidth 80 MHz EMC and immunity EMC interference immunity EN 61000-4-2 Electrostatic discharge Contact discharge ±4 kV Air discharge ±8 kV Installation BAT867-R Release 06 08/2018... -
Page 43: Network Range
Length of a twisted pair segment max. 328 ft (100 m) (for Cat5e cable) Table 15: Network range: 10/100/1000 Mbit/s twisted pair port Power consumption/power output Power consumption Power output 31.0 Btu (IT)/h Table 16: Power consumption/power output Installation BAT867-R Release 06 08/2018... -
Page 44: Scope Of Delivery, Order Numbers And Accessories
The "Antenna Guide" document provides an overview of the antennas that can be used as well as the suitable antenna accessories. This document is available for download as a PDF file on the Hirschmann product pages (www.hirschmann.com). - Page 45 Other accessories Order number 50 Ω terminating resistors for sealing unused antenna connections, N 942 117-001 (10 pieces) Installation BAT867-R Release 06 08/2018...
-
Page 46: 10 Underlying Technical Standards
Information technology equipment – Safety – Part 1: General requirements The device has an approval based on a specific standard only if the approval indicator appears on the device casing. The device generally fulfills the technical standards named in their current versions. Installation BAT867-R Release 06 08/2018... -
Page 47: A Further Support
Further support Technical questions For technical questions, please contact any Hirschmann dealer in your area or Hirschmann directly. You find the addresses of our partners on the Internet at http:// www.hirschmann.com. A list of local telephone numbers and email addresses for technical support...
