Model 3130 Downflow
Service Manual
IMPORTANT: Fill in pertinent information on page 2 for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3130 and is the answer not in the manual?

Questions and answers

Related Manuals for Fleck 3130

Summary of Contents for Fleck 3130

  • Page 1 Model 3130 Downflow Service Manual IMPORTANT: Fill in pertinent information on page 2 for future reference.

  • Page 2: Job Specification Sheet

    MODEL 3130 Downflow Job Specification Sheet • JOB NO. __________________________________________________________ • *MODEL NO. ______________________________________________________ • WATER TEST ______________________________________________________ • CAPACITY PER UNIT _______________________________________________ • MINERAL TANK SIZE DIA.________ HEIGHT_________ • BRINE TANK SIZE & SALT SETTING PER REGENERATION: _________________________________ * CONTROL VALVE SPECIFICATIONS...

  • Page 3: General Commercial Pre-Installation Check List

    MODEL 3130 Downflow General Commercial Pre-Installation Check List WATER PRESSURE: A minimum of 25 pounds of water pressure is required for regeneration valve to operate effectively. ELECTRICAL FACILITIES: A continuous 115 volt, 60 Hertz current supply is required. (Other voltages available.) Make certain the current supply is always hot and cannot be turned off with another switch.
  • Page 4 MODEL 3130 Downflow Water Conditioner Flow Diagrams Page 4 Printed in U.S.A.
  • Page 5 MODEL 3130 Downflow Water Conditioner Flow Diagrams (Cont’d.) Page 5 Printed in U.S.A.
  • Page 6 MODEL 3130 Downflow Water Conditioner Flow Diagrams (Cont’d.) Page 6 Printed in U.S.A.
  • Page 7 MODEL 3130 Downflow Water Conditioner Flow Diagrams (Cont’d.) Page 7 Printed in U.S.A.
  • Page 8 MODEL 3130 Downflow Water Conditioner Flow Diagrams (Cont’d.) Page 8 Printed in U.S.A.
  • Page 9 MODEL 3130 Downflow Water Conditioner Flow Diagrams (Cont’d.) Page 9 Printed in U.S.A.
  • Page 10 MODEL 3130 Downflow Control Valve (See opposite page for parts list) Page 10 Printed in U.S.A.
  • Page 11 13 ..1 ... 40310 ....
  • Page 12 MODEL 3130 Control Drive Assembly (see opposite page for parts list) Page 12 Printed in U.S.A.
  • Page 13 MODEL 3130 Control Drive Assembly Parts List Item No. Quantity Part No. Description 1 ... 1 ... 40200-00 ... . . Backplate 2 .
  • Page 14 MODEL 3130 Downflow 1705 Brine System (See opposite page for parts list) Page 14 Printed in U.S.A.
  • Page 15 MODEL 3130 Downflow 1705 Brine System Parts List Item No. Quantity Part No. Description 1 ... . 1 ... . . 14792 ....End Plug 2 .
  • Page 16 MODEL 3130 2″ Plastic Meter Assembly Item No. Quantity Part No. Description 1 ... 1 ... . 17689....Body, Meter, 2″ Plastic 2 .
  • Page 17 MODEL 3130 2″ Meter Brass Assembly Item No. Quantity Part No. Description 1 ... .1 ... . 14456 ....Meter Body 2 .
  • Page 18  MODEL 3210 ECONOMINDER Timer Assembly (See opposite page for parts list) Page 18 Printed in U.S.A.
  • Page 19  MODEL 3210 ECONOMINDER Timer Assembly Parts List Item No. Quantity Part No. Description 1 ... 1 ... 13870-01 ... . . Timer Housing Assembly 2 .
  • Page 20  MODEL 3210 ECONOMINDER Commercial Demand Regeneration Control Timer Settings Typical Programming Procedure How To Manually Regenerate Your Water Conditioner At Any Time: Calculate the gallon capacity of the system, subtract the necessary reserve requirement and set the gallons Turn the manual regeneration knob clockwise one “click.” required by lifting the gallon dial and rotating it so that the This slight movement of the manual regeneration knob number of gallons required is aligned with the white dot...

  • Page 21: Timer Setting Procedure

    MODEL 3200 TIMER Timer Setting Procedure How To Set Days On Which Water Conditioner Is To Regenerate: Rotate the skipper wheel until the number “1” is at the red SERVICE 24 HR. GEAR POSITION pointer. Set the days that regeneration is to occur by sliding MANUAL REGENERATION KNOB INDICATOR tabs on the skipper wheel outward to expose trip fingers.
  • Page 22 MODEL 3200 & 3210 TIMER SERIES Regeneration Cycle Program Setting Procedure How To Set Regeneration Cycle Program: The regeneration cycle program on your water conditioner PROGRAM BRINE & RINSE WHEEL FOR SECTION has been factory preset, however, portions of the cycle or CONTROL OF (2 MIN.
  • Page 23 MODEL 3130 Downflow Service Instructions PROBLEM CAUSE CORRECTION 1. Softener fails to regenerate. A. Electrical service to unit has been A. Assure permanent electrical service interrupted. (check fuse, plug, pull chain or switch). B. Timer is defective. B. Replace timer.
  • Page 24 MODEL 3130 Downflow Service Instructions (Cont’d.) PROBLEM CAUSE CORRECTION 7. Excessive water in brine A. Plugged drain line flow control. A. Check flow control. tank. B. Plugged injector system. B. Clean injector and screen. C. Timer not cycling. C. Replace timer.
  • Page 25 SYSTEM #4 Single Meter System Wiring Diagram Immediate or Delayed Regeneration Page 25 Printed in U.S.A.
  • Page 26 SYSTEM #4 WITH REMOTE METER Single Meter System Wiring Diagram Immediate or Delayed Regeneration Page 26 Printed in U.S.A.
  • Page 27 SYSTEM #5 2 Meter Interlock Wiring Diagram Page 27 Printed in U.S.A.
  • Page 28 SYSTEM #6 Series Regeneration Wiring Diagram Page 28 Printed in U.S.A.
  • Page 29 SYSTEM #7 24V/120V - Alternator Wiring Diagram Page 29 Printed in U.S.A.
  • Page 30 SYSTEM #7 230V - Alternator Wiring Diagram Page 30 Printed in U.S.A.
  • Page 31 MODEL 3130 System #4 - Typical Single Tank Installation With Optional Meter MANUAL SHUTOFF OPTIONAL 3100 METER DRAIN 3 WIRE POWER CORD BRINE LINE BRINE TANK RESIN TANK System #5 Interlock - Typical Twin Tank Installation with Optional Meter Interlock and No Hard Water Bypass...
  • Page 32 MODEL 3130 System #6 - Twin Series Regeneration Installation with a Remote Meter DIAPHRAGM OPERATED VALVE METER MANUAL SHUTOFF PRESSURE SUPPLY TO S.V.O. 3 WIRE POWER CORD drain ELECTRICAL INTERLOCK CORD BRINE LINE RESIN TANK UNIT 1 BRINE TANK RESIN TANK...
  • Page 33 MODEL 3130 3130 Outline Drawing Page 33 Printed in U.S.A.
  • Page 34 MODEL 3130 Downflow Flow Data & Injector Draw Rates Page 34 Printed in U.S.A.

  • Page 35: Service Assemblies

    1 ..16130..Piston 1 ..40205..Piston Rod, 2930/3130 60621 2″...
  • Page 36 P/N 40354 Rev. 0 3/00 Printed 3/00...
