Ningbo Ginlong Technologies Co., Ltd.
No. 57 Jintong Road, Binhai Industrial Park,
Xiangshan, Ningbo, Zhejiang, 315712, P.R.China
Tel: +86 (0)574 6578 1806
Fax: +86 (0)574 6578 1606
Email: info@ginlong.com
Web: www.ginlong.com
Please record the serial number of your inverter and quote this when you contact us.
PV Grid Tie Inverter
Solis Single Phase Inverter
Installation and Operation Manual
2014, Ningbo Ginlong Technologies Co., Ltd.
C
-US version
Ver 2.5
Advertisement
Table of Contents
Related Manuals for Ginlong Solis Series
Summary of Contents for Ginlong Solis Series
- Page 1 Xiangshan, Ningbo, Zhejiang, 315712, P.R.China Tel: +86 (0)574 6578 1806 Fax: +86 (0)574 6578 1606 Email: info@ginlong.com Web: www.ginlong.com Please record the serial number of your inverter and quote this when you contact us. 2014, Ningbo Ginlong Technologies Co., Ltd. Ver 2.5...
-
Page 2: Table Of Contents
Contents ……………………………………………… 1. Introduction 1.1 Product Descriptions ………………………………… 1.2 Packaging ………………………………………… 2. Safety Instructions ……………………………………… 2.1 Safety Symbols …………………………………… 2.2 General Safety Instructions ……………………… ……………………………………… 2.3 Notice For Use ……………………………………………… 3. Overview 3.1 Front Panel Display ……………………………… 3.2 LED Status Indicator Lights ………………………... -
Page 3: Introduction
1. Introduction Contents 1.1 Product Descriptions 6. Operation ………………………………………………… Solis single phase US series inverters can transfer DC power from PV panels into AC …………………………………………… 6.1 Main Menu power and feed into grid. Solis single phase US series inverters contain 9 models which are listed below: ……………………………………………... -
Page 4: Packaging
Solis Single Phase Inverter -US version Installation and Operation Manual CAUTION: CAUTION, HOT SURFACE symbol indicates safety instructions, which if not correctly followed, could result in burns. 2014, Ningbo Ginlong Technologies Co., Ltd. Ver 2.3 2.2 General Safety Instructions Description Number Part NO. -
Page 5: Notice For Use
3. Overview 2.Safety Instructions 3.1 Front Panel Display WARNING: To reduce the risk of fire, over-current protective devices (OCPD) are required for circuits connected to the Inverter. The DC OCPD should be installed as local requirement. All photovoltaic source and output circuit conductors shall have disconnects complying with the NEC, Section 690, Part II. -
Page 6: Keypad
3. Overview 4. Installation 3.3 Keypad 4.1 Select a Location for the Inverter To select a location for the inverter, the following criteria should be considered: There are four keys in the front panel of the Inverter(from left to right): ESC, UP, DOWN and ENTER keys. -
Page 7: Mounting The Inverter
4. Installation 4. Installation 4.2 Mounting the Inverter 3. Carefully hang the inverter on the upper part of the wall mount bracket by fitting the hooks into the slot of the bracket. Use M4×25 stainless steel screws and washers at holes E and F (in Figure 4.2) to secure the mounting hooks to the rear of the inverter. Please use suitable fixings for wall type (e.g. - Page 8 4. Installation 4. Installation Connect PV side of inverter: Before electrical connection Please make sure below steps are strictly followed: Warning a. Switch the Grid Supply Main Switch (AC) OFF. Before connecting inverter, please make sure the PV array open circuit voltage is b.
-
Page 9: Start & Stop
The red LED power will light, and the LCD shows the company's name and the inverter model. 208V~ 240V~ 3PH-△-3W SPLIT-PHASE Ginlong Solis-5K-2G-US TERMINAL Connection requiement Optional Figure 5.1 Company Name and Inverter Model on LCD Table 4.1 Grid terminal connection... -
Page 10: Operation
6. Operation 6. Operation During normal operation, the display alternately shows the power and the operation Display Description Duration status with each screen lasting for 10 seconds (see Figure 6.1). Screens can also be scrolled manually by pressing the UP and DOWN keys. Press the ENTER key to V_DC1: Shows input 01 voltage value. -
Page 11: Settings
6. Operation 6. Operation 6.3 Settings 6.4 Advanced Info - Technicians Only The following submenus are displayed when the Settings menu is selected: NOTE: 1. Set Time To access to this area is for fully qualified and accredited technicians only. 2. -
Page 12: Temperature
6. Operation 6. Operation 6.5 Advanced Settings - Technicians Only 6.4.2 Temperature NOTE: The screen shows the temperature inside the inverter (see Figure 6.7). To access to this area is for fully qualified and accredited technicians only. Please follow 6.4 to enter password to access this menu. Temperature 046.6 ℃... -
Page 13: Grid On/Off
6. Operation 6. Operation Selecting the “User-Def” menu will access to the following submenu (see Figure 6.12), 6.5.3 New Password This function is used to set the new password for menu “Advanced info.” and “Advanced OV-V: 262V UN-V: 210V information” (see Figure 6.14). Figure 6.12 YES=<ENT>... -
Page 14: Maintenance
8. Trouble Shooting 6. Operation Alarm Message Failure description During normal operation, If arc fault happen in DC circuit, the inverter will stop output and Over grid voltage OV-G-V LCDshow below: Under grid voltage UN-G-V ARC-Fault Over grid frequency OV-G-F Restart<ESC>... - Page 15 Solis-1K-2G-US Solis-1.5K-2G-US Solis-2K-2G-US Solis-2.5K-2G-US 70~400Vdc 208V/240V 208V/240V 183~228(for208V rated)/211~264(for240V rated) 183~228(for208V rated)/211~264(for240V rated) THD<3% THD<3% >96.8% >97.5% >96.8% 339W*657H*164D mm 339W*657H*172.5D mm 339W*657H*164D mm(13.3W*25.9H*6.5D inch) (13.3W*25.9H*6.5D inch) (13.3W*25.9H*6.8D inch) 9.8kg/21.6lb 15kg/33.1lb 9.8kg/21.6lb DC Switch Optional DC Switch Optional -13°F~140°F -13°F~140°F NEMA 4X NEMA 4X CAN/CSAC22.2 N107.1, UL1741, UL1998, UL1699B, FCC part 15, Class B...
- Page 16 Solis-3K-2G-US Solis-3.6K-2G-US 208V/240V 208V/240V 183~228(for208V rated)/211~264(for240V rated) 183~228(for208V rated)/211~264(for240V rated) THD<3% THD<3% >97.5% >97.5% 339W*657H*172.5D mm(13.3W*25.9H*6.8D inch) 339W*657H*172.5D mm(13.3W*25.9H*6.8D inch) 15kg/33.1lb 15kg/33.1lb DC Switch Optional DC Switch Optional -13°F~140°F -13°F~140°F NEMA 4X NEMA 4X CAN/CSAC22.2 N107.1, UL1741, UL1998, UL1699B, FCC part 15, Class B CAN/CSAC22.2 N107.1, UL1741, UL1998, UL1699B, FCC part 15, Class B 0-100% 0-100%...
- Page 17 Solis-4K-2G-US Solis-4.6K-2G-US 10+18Adc 10+18Adc 2/(1 and 2) 2/(1 and 2) 208V/240V 208V/240V 183~228(for208V rated)/211~264(for240V rated) 183~228(for208V rated)/211~264(for240V rated) THD<3% THD<3% >97.8% >97.8% 339W*657H*172.5D mm(13.3W*25.9H*6.8D inch) 339W*657H*172.5D mm(13.3W*25.9H*6.8D inch) 17kg/33.1lb 17kg/33.1lb DC Switch Optional DC Switch Optional -13°F~140°F -13°F~140°F NEMA 4X NEMA 4X CAN/CSAC22.2 N107.1, UL1741, UL1998, UL1699B, FCC part 15, Class B CAN/CSAC22.2 N107.1, UL1741, UL1998, UL1699B, FCC part 15, Class B...
- Page 18 Solis-5K-2G-US 10+18Adc 2/(1 and 2) 208V/240V 183~228(for208V rated)/211~264(for240V rated) THD<3% >97.8% 339W*657H*172.5D mm(13.3W*25.9H*6.8D inch) 17kg/33.1lb DC Switch Optional -13°F~140°F NEMA 4X CAN/CSAC22.2 N107.1, UL1741, UL1998, UL1699B, FCC part 15, Class B 0-100% .32.
