User Manual
for 5G Series Grid Inverter
Applicable models
Solis-185K-EHV-5G-US
Solis-255K-EHV-5G-US
Solis-125K-EHV-5G-US-PLUS
Solis-185K-EHV-5G-US-PLUS
Solis-255K-EHV-5G-US-PLUS
Version 1.6, Release Date: 11,2022
