Summary of Contents for Iwata Full Finish G-Series G6
- Page 1 取扱説明書 | Operating Instruction Manual...
- Page 2 When airbrush projects call for larger coverage, look no further than the Iwata G-Series airbrush-guns. They spray with the fine atomization and air pressure of an airbrush. For full finishes, ANEST IWATA spray guns offer superior atomization for a reliable and consistent finish.
-
Page 3: Need Assistance
NEED ASSISTANCE If you have any issues or warranty service questions, contact your local ANEST IWATA a liate before returning to your place of purchase. ANEST IWATA-MEDEA, INC. ANEST IWATA CORPORATION ANEST IWATA AUSTRALIA PTY LTD. Portland, Oregon U.S.A. Yokohama, Japan Mt. - Page 4 FEATURES Iwata G-Series G6 • MAC Valve for precise control of air and spray • G6 head system • Spray width: 5/8” up to 2.5”+ • Long tapered needle for smooth transition between medium to extra wide spray • Dual-purpose air cap and fan...
- Page 5 Iwata G-Series G5 Iwata G-Series G3 • True center-post gravity-feed airbrush • True center-post gravity-feed airbrush • MAC Valve for precise control of air • MAC Valve for precise control of air and spray and spray • G5 head system •...
- Page 6 FOR G-SERIES G6 Fluid Adjustment Knob (#22) Pattern Adjustment Set (#14) The fluid adjustment knob limits how much fluid will be sprayed This adjustment creates a circular- or oval-shaped spray pattern. when the trigger is pulled all the way back. After setting the spray When the valve is fully closed, twisted fully clockwise, the spray pattern (see #14 description), the fluid adjustment knob sets the pattern will be a round shape.
-
Page 7: Getting Started
GETTING STARTED Pre-Check The Settings 3. Screw the bottle onto the airbrush-gun. 1. Close the pattern adjustment knob (#14) fully by gently twisting it clockwise until it stops. It doesn’t need to be tight. 4. Adjust the air source pressure to 35-55 psi and spray. 2. -
Page 8: General Operation
GENERAL OPERATION Fine-Line Spray Control spray consistency over large areas by setting 1. Pull the trigger back slightly to start the air. the fluid adjustment knob (#22) to limit the amount of paint volume sprayed. 2. Position the airbrush close to the surface. About 1 inch or 2.5 cm. -
Page 9: Maintenance
MAINTENANCE Cleaning After Each Session Cleaning Between Colors Or any time the airbrush-gun becomes clogged: 1. Replace the color bottle with a bottle containing the appropriate 1. Increase the air pressure. cleaning solution (when using the G6 Bottle Set). Rinse out metal cup and fill with cleaning solution. - Page 10 16-1 16-2...
- Page 11 PRICE ITEM ALSO PRICE ITEM ALSO ITEM DESCRIPTION CODE FITS ITEM DESCRIPTION CODE FITS Air Valve Shaft I2023 RG-3/LPH-50 Air Cap I6001 Air Valve Seat Set I2052 RG-3/LPH-50 I6004 CA PROP CA PROP 16-1 Gasket Air Valve Seat I2171 I6005 16-2 O-ring I6601...
- Page 12 All Iwata airbrushes are warranted against all manufacturing defects of material and manufacture or workmanship for a period of FIVE years from date of purchase. This warranty does not cover needles, nozzles, o-rings and internal packings since these parts need to be replaced occasionally due to normal wear. Any other parts or materials that are or become defective so as not to be usable within this period will be repaired or replaced.
- Page 14 CAUTION エアーブラシ全体を液体に浸さないで下さい。 カップに塗料、 洗浄液、 などを入れたままエアーブラシを保管しないで下さい。...
- Page 16 ヘッ ドシステム ECL903-IM-KMA...
