Summary of Contents for Iwata AZ3 HTE P.A.S. Concept
- Page 1 USE and MAINTENANCE INSTRUCTION MANUAL • AZ3 HTE P.A.S. G R A V I T Y with Pressurized Cup 600ml SPRAY GUN Series...
-
Page 2: Technical Data
AZ3 HTE P.A.S. TECHNICAL DATA Technical AZ3 HTE P.A.S. HTE-P1 DIAGRAM TO ILLUSTRATE PRESSURE REGULATION INSIDE CUP Refer Chapter 5.5 “HOW TO ADJ. PRESSURE INSIDE CUP” Turns of knob IMPORTANT INFORMATIONS CAUTION Do not lay the gun down. The air regulator can be damaged if Do not open the lid while pulling the trigger. - Page 3 AZ3 HTE P.A.S. Before use, adjustment or maintenance, it is important IMPROPER USE to read this instruction manual very carefully. This manual must be stored in a safe place for any future 1. Never point gun towards people or animals. reference.
- Page 4 AZ3 HTE P.A.S. 5. MAINTENANCE AND INSPECTION - When you remove needle packing nut (10), don’t leave the two plastic parts of needle packing set CAUTION in the gun body. - Try to adjust it carefully while pulling trigger and Before carrying out maintenance and inspection ALWAYS confirming movement of fluid needle set (9).
-
Page 5: Spare Parts List
AZ3 HTE P.A.S. 7. SPARE PARTS LIST 6. TROUBLESHOOTING 19-5 GUN DOES NOT SPRAY 19-4 19-3 - Fluid adj. knob (6) closed. Check and adjust. - Tip hole of nozzle (2) obstructed. Check and clean. - Paint filter obstructed. Check and clean. - Non drip obstructed.
