- Page 1 IWATA TR1 & TR2 MANUAL & PARTS GUIDE...
-
Page 2: Need Assistance
If you have any issues with this product, call ANEST IWATA-MEDEA (U.S.A.) 503-253-7308 (M-F 8AM - 4:30PM Paci c Time) or your local ANEST IWATA a liate before returning to your place of purchase. ANEST IWATA-MEDEA, INC. ANEST IWATA CORPORATION ANEST IWATA AUSTRALIA PTY LTD. - Page 3 Revolution Congratulations on your purchase of an Iwata ™ airbrush, a versatile, reliable and dependable airbrush. The Revolution was designed for the new airbrush user or hobbyist seeking Iwata’s famous superior spray quality combined with multi-purpose versatility. VALUE, QUALITY & PERFORMANCE...
- Page 4 • Replaceable, internal PTFE needle packing for use with solvent-based paints. • .3 mm Needle/Nozzle/Nozzle Cap combination. • FA450 Iwata Pistol Grip Filter defends against moisture. • Side-feed airbrush design allows the use of side-feed bottles and cups. • .25 oz side-mounted color cup.
- Page 5 • Replaceable, internal PTFE needle packing for use with solvent-based paints. • .5 mm Needle/Nozzle/Nozzle Cap combination. • FA450 Iwata Pistol Grip Filter defends against moisture. • Side-feed airbrush design allows the use of side-feed bottles and cups. • .5 oz side-mounted color cup.
- Page 6 1. Pull the trigger (#9) back slightly and only the air will come out. Stippling 2. Pull the trigger back more until paint starts to spray Iwata airbrushes are designed to produce a wide range of stippling in small amounts. textures. 3. Pulling the trigger back further releases even more paint 1.
- Page 7 Line thickness can be controlled by adjusting the distance done and what textures are desired. A good working pres- between the airbrush and the surface and also by varying the sure may average around 25 psi. The viscosity of the paint and paint flow by manipulating the trigger’s position.
-
Page 8: Maintenance
MAINTENANCE Choose an Cleaning the Airbrush Between Colors Before Each Session 1. Dump out the color cup’s excess paint. Spray water, or the appropriate paint solvent, through the 2. Rinse the cup with the appropriate cleaning solution. airbrush to make sure the airbrush is working properly. 3. - Page 9 Periodically DO NOT over-lube the needle or the main lever mechanism, To ensure smooth main lever action lubricate the needle since it is possible to transfer excess lube into the nozzle (#17) and the main lever mechanism (#10 or #11) regularly. causing severe paint flow problems.
-
Page 10: Troubleshooting Procedures
TROUBLESHOOTING PROCEDURES Symptom Problem Solution •Bubbles in color cup or bottle •Loose nozzle cap •Tighten (#2) finger tight •Improper nozzle to body connection •See nozzle (#3) to reseat the nozzle •Cracked or damaged nozzle •See nozzle (#3) to replace the nozzle •Double line •Dried paint on needle tip (Tip-Dry) •See cleaning the needle... - Page 11 TROUBLESHOOTING PROCEDURES Symptom Problem Solution •Skipping •Dried paint on needle tip (Tip-Dry) •Clean with cotton swab dipped in cleaner •Pigment too thick •See paint preparation •Air pressure too high •See specific compressor instructions to lower the air pressure •Improper nozzle to body connection •See nozzle (#3) to reseat the nozzle •Dirty airbrush •See cleaning the airbrush between colors...
-
Page 12: Replacement Parts And Accessories
Needle (#13) High Strength translucent bottles, Iwata-Medea offers a wide Iwata needles are made of precision ground and hardened stainless assortment of bottles for every application. steel that will withstand prolonged usage. They are, however,... - Page 14 Pistol-Grip Filter For clean, dry air- ow. The Iwata Revolution Attaching directly onto the airbrush, the Iwata-Medea Pistol-Grip Filter is the TR1 and TR2 Series final defense to deliver clean, dry air to your airbrush. Miniature in size, the super-...
- Page 16 — I W A T A R E V O L U T I O N T R 1 / T R 2 A I R B R U S H E S • M A S T E R P A R T S L I S T — PRICE ITEM ALSO...
- Page 17 Copyright © 2009 Iwata-Medea Inc. All rights reserved. The Iwata-Medea logo, Iwata-Medea®, Iwata Eclipse™, Iwata Revolution™, Iwata Kustom™, Iwata Micron™, Sprint Jet™, Smart Jet™, Power Jet Pro™, Power Jet Lite™, Medea Super Lube ™, Pistol Grip Filter™, and all products denoted with ® or ™ are registered trademarks or trademarks of Iwata-Medea Inc. • Iwata® and the...
