ETS PARAMETERISATION
The Manual Control is configured from the Configuration tab itself under Manual
Control.
The only two parameters are:
Manual Control [Disabled / Only Test Off Mode / Only Test On Mode /
Off Mode + Test On
permit using the manual control under the Test Off, the Test On, or both
modes. Note that, as stated before, using the Test Off mode does not require
any special action, while switching to the Test On mode does require long-
pressing the Prog/Test button.
Manual Control Lock [enabled/disabled]: unless the above parameter has
been "Disabled", the Lock Manual Control parameter provides an optional
procedure for locking the manual control in runtime. When this checkbox is
enabled, object "Manual Control Lock" turns visible, as well as two more
parameters:
➢ Value [0 = Lock; 1 = Unlock /
manual control lock/unlock should take place respectively upon the
reception (through the aforementioned object) of values "0" and "1", or the
opposite.
➢ Initialization [Unlocked / Locked /
the manual control should remain after the device start-up (after an ETS
download or a bus power failure). "Last Value" (default; on the very first
start-up, this will be Unlocked.
1
The default values of each parameter will be highlighted in blue in this document, as
follows: [default/rest of options].
http://www.zennio.com
Figure 5. Manual Control
1
Mode] . Depending on the selection, the device will
0 = Unlock; 1 =
Last
Technical Support:
Lock]: defines whether the
Value]: sets how the lock state of
http://support.zennio.com
MAXinBOX 24
Test
13
