INSTALLATION MANUAL FOR
SSC-500 CONTROL SYSTEMS
ON HYDRAULIC PRESSES
Operator Interface
Keypad/Display
Program/Run
Selector Switch
Remote Operator
Station (Optional)
IMPORTANT:
PUBLICATION BEFORE INSTALLING, OPERATING OR
MAINTAINING THE SOLID-STATE HYDRAULIC PRESS
ELECTRICAL CONTROL SYSTEM.
5795 Logistics Parkway • Rockford, Illinois 61109 • Toll Free 1-800-922-7533 (USA only) • Phone (815) 874-7891
Fax (815) 874-6144 • Web Site: www.rockfordsystems.com • E-Mail: sales@rockfordsystems.com
PLEASE REVIEW THIS ENTIRE
Manual No. KSL-249
SSC-500 Control Box
(Not Shown)
