Summary of Contents for Magnavox MHT983
- Page 2 2ANH7-393MET1426 FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Location Of Control
LOCATION OF CONTROL FRONT VIEW TOP VIEW VOLUME SOURCE LIGHT LINE IN STANDBY / AUXIN 10 11 REAR VIEW DC IN LINE IN AUX IN 16 17... -
Page 4: Location Of Controls
LOCATION OF CONTROLS Loud Speakers with LED Decorative Lights Subwoofer with LED Decorative Lights Remote Sensor Cradle (To hold Remote Control/External Audio Player/Cell Phone) DJ Scratching Effect Knob SOURCE Button LIGHT On/Off Button Standby On/Off Button (Skip Backward) Button (Play/Pause) Button (Skip Forward) Button (Bluetooth) Indicator LINE IN Indicator... - Page 5 LOCATION OF CONTROL (REMOTE CONTROL) SOURCE MUTE LIGHT Standby On/OFF Button SOURCE Button (Volume Up) Button (Skip Backward) Button (Play/Pause) Button (Skip Forward) Button MUTE Button (Volume Down) Button LIGHT Button...
-
Page 6: Power Source
POWER SOURCE Connect the small plug from the supplied AC/DC Adaptor to the DC 12V Jack on the rear of unit. Connect the AC/DC Adaptor into any convenient household outlet has AC 100-240V, 50/60Hz as illustrated below. The STANDBY/AUX IN Indicator on the top of unit will illuminate. -
Page 7: Battery Precautions
BATTERY PRECAUTIONS: Follow these Battery Precaution when using a battery in this device: Use only the size and type of battery specified. Be sure to follow the correct polarity when installing the battery as indicated in the battery compartment. A reversed battery may cause damage to the device. Do not mix different types of batteries together (e.g. -
Page 8: Operation
OPERATION General Operation: Connect the unit to AC power as previously instructed. The unit will enter to standby mode and the STANDBY/AUX IN Indicator on the top of unit will illuminate. Press the Button on the unit or Remote Control to power on the unit from standby mode. - Page 9 The STANDBY/AUX IN Indicator on the top of unit will illuminate. Notes: • When the external BT Device searched the unit, our model number “MHT983” will appear on the display of external BT Device. • If while pairing you are asked for a code please try "0000" or "1234".
- Page 10 LINE IN: Listen from an external Audio Player such as MP3 Player, Discman…etc. In power off mode, connect one end of supplied Audio Connection Cable to the AUX Out/Line Out/Phone Jack on the external Audio Player. Connect the other end of the cable to the AUX IN Jack on the rear of unit as illustrated below: REAR VIEW DC IN...
-
Page 11: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Check the following before requesting service: SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION Can’t power on The unit has not connected to Connect the supplied AC/DC AC power outlet Adaptor to the unit and AC wall outlet No sound or weak Volume of the unit was set to Increase the volume level sound... -
Page 12: General Specifications
GENERAL SPECIFICATIONS: Power Source: .............. 12V, 2A, Impedance of Speakers: Loud Speaker: ................10W; 8Ω x 2 Subwoofer: ..................20W; 4Ω Audio Power: Loud Speakers: ........... 5W x 2 (Total 10W, RMS) Subwoofer: ................15W (RMS) BT Version: ....................BT Operation Distance: ..........≤... -
Page 13: Limited Warranty
LIMITED WARRANTY...
