- Page 1 AMAZON ALEXA VOICE ACTIVATED WIFI SPEAKER with Bluetooth Wireless Technology ® OWNER'S MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT. MODEL: MSH315V Size: 148.5(W) x 210(H)mm (A5)
- Page 2 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product`s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Portable Cart Warning...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
-
Page 5: Location Of Controls
LOCATION OF CONTROLS Main Unit: Top View MODE VOL+ VOL- Rear View 1. Decorative Ring with LED Lights 7. Indicator 8. Built-in Microphone /MODE Button 9. Charge Indicator 3. VOL (Volume) + Button 10. DC 5V (In) Jack 4. VOL (Volume) - Button (Micro USB Port) /WPS (Microphone Off/Wi-Fi Protected Setup) Button... - Page 6 LOCATION OF CONTROLS Bottom View Charging Station: Top View Rear View 12. Charging Contacts 13. DC 5V (In) Jack (Micro USB Port)
-
Page 7: Power Source
POWER SOURCE The unit has a built-in Li-ion rechargeable battery, charge it before use or when it is drained as below: Charging Through the Unit Directly: 1.Open the rubber cover on the rear of unit as illustrated below: 2. Connect the Micro USB Plug from the supplied AC/USB Adaptor to the DC 5V (In) Jack (Micro USB Port). - Page 8 3. Place the unit to the Charging Station as illustrated below: To DC 5V (In) jack on the charging station To wall outlet AC/USB Adaptor 4. While charging, the Red Charging Indicator on the top of unit will illuminate. When finished charging, it will turn off. Notes: 1.
- Page 9 Notes: When the external BT Device searches for the unit, our model number "MSH315V" will appear on the display of external BT Device. If while pairing you are asked for a code please try "0000" or "1234".
- Page 10 Normal operation after pairing: 1. Power on the external BT Device and enter to BT mode. 2. Press and hold the /MODE Button on the top of unit to power on. The Blue and Green Indicators on the top of unit will illuminate and blink. 3.
- Page 11 AUX IN MODE To listen from an external Audio Player such as a MP3 Player, Discman …etc. 1. Connect one end of the supplied Audio Connection Cable to the AUX Out/Line Out/Phone Jack on the external Audio Player. 2. Open the Rubber Cover, connect the other end of the cable to the AUX IN Jack as illustrated below: 3.
- Page 12 2. Wait approximately 25 seconds until the Blue Indicator is not lit. (Only the Green Indicator will illuminate and blink). 3. Power on your Mobile Device and turn on the preloaded Apps “MAGNAVOX Alexa Player (By CRAIG)”. The following picture...
- Page 13 4. Wait until the following page appears. Then connect your unit into the Wi-Fi network as instructed below following on-screen prompts: Touch/tap the "Wi-Fi Setup Wizard" Button on the screen. Searching for MAGNAVOX Wireless Hi-Fi System... Please make sure your device is powered up.
- Page 14 6. The following page will appear. Enter the password then touch/tap the “Next” Button on the screen. < WIFI INFO Please enter Wi-Fi password: Wi-Fi: "Your WiFi network" Password: Please enter Wi-Fi password Next 7. The following page will appear. Press and hold the /WPS Button on the top of unit until audible prompt “Connecting to your network, this may take one to three minutes”...
- Page 15 8. While connecting, the following page will appear. < PLEASE WAIT Wait for device to be connected to Wi-Fi... Don't operate device during the Wi-Fi setup. Please wait for the completion of the setup patiently. It's usually finished in 60 seconds. Cancel If you hear voice prompt for an erro, please go back and retry.
- Page 16 Note: If the connection fails, the following page will appear. WI-FI SETUP TIMEOUT UH OH! Unable to connect your MAGNA... Alternate Way to Setup Cancel to reconnect following the on screen Then touch/tap the "Cancel" Button instructions again.
- Page 17 10. If connection is successful, the following screen will appear, touch/tap 'Custom...' to change the location name of the unit. Or, touch/tap one of the location in the name list as desired. Then touch/tap the "Next" Button to save the setting. <...
- Page 18 12. The following page will appear, input the account and password and touch/tap the "Sign in" Button on the screen to log on. < AMAZON LOGIN Sign in to MSH315V using your Amazon account Sign in Forgot password? Email (phone for mobile accounts)
- Page 19 14. When the following page appears, touch/tap the "I agree" Button to log in Amazon. < AMAZON LOGIN MSH315V We will provide MSH315V: Connectivity to Alexa so that you can interact with it using your voice. You also accept All Amazon terms found here...
-
Page 20: Main Menu
16. The following page will appear, touch/tap the "Next" Button on the screen. MSH315Vxxxx Alexa is ready Here are some of the many things you can ask Alexa. Alexa, what's the weather? Alexa, play my Flash Briefing. Alexa, what are some top- rated Indian restaurants? Alexa, set a timer for 20 minis. - Page 21 18. The main menu will appear as seen below. Set or reset the settings following the on screen instructions as seen below: < DEVICE LIST MSH315V_xxxx No song Play All Touch/tap the " " to add more units to the network, repeat the procedure above and make connection as following on screen instructions.
- Page 22 19. If more than one unit has been added into the DEVICE LIST, you can “ ” touch/tap the instruction to learn how to switch solo and muti mode as seen below: < DEVICE LIST Bedroom You Belong with me MSH315V_xxxx No song ............
- Page 23 The Green Indicator will stop blinking and audible prompt "Connected" will be heard. 5. Power on your Mobile Device and turn on the pre-installed Apps "MAGNAVOX Alexa Player (By CRAIG)". The following image will appear on the Mobile Device's screen: 6.
- Page 24 7. Touch/tap the mobile device's screen and slide to right repeatedly until the following selection menu appears. Then touch/tap the corresponding button to enter to the desired functions as below: Search Touch to search online songs Touch to listen the Favorites collected favorite songs Touch to listen the music...
- Page 25 1. Power on the unit; connected the unit to Wi-Fi network as previously instructed. 2. Power on your mobile device, open the "MAGNAVOX Alexa Player (By CRAIG)" Apps enter to the selection as instructed earlier. The White color Decorative Ring will illuminate.
- Page 26 5. During Amazon Alexa operation, you can use the following voice command to control the unit: Voice command: (Alexa)---play the song <XX> (XX=Name of the desired song)! Action: The song will be played. Voice command: (Alexa) --- pause/stop the song! Action: The song will be paused or stopped.
-
Page 27: Troubleshooting
TROUBLESHOOTING Check the following before requesting service: SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION Can’t power on Built in battery drained Recharge the battery Volume level in minimum position Rise the volume level by press No sound or the VOL + Button on the top sound weak of unit Volume level of paired/connected device... -
Page 28: Specifications
SPECIFICATIONS Power source: Built-in DC 3.7V, 2500mAh (9.25 WH) rechargeable Li-ion Battery, Recharge by DC 5V through DC 5V (In) Jack (Micro USB Port) on the unit or Charging station Port BT Version: about 32 Feet in open area BT Operation Distance: Wifi Type: IEEE 802.11 b/g/n about 96 Feet in open area... - Page 29 This product has been manufactured by and is sold under the responsibility of Craig Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product. MAGNAVOX and SMART. VERY SMART are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V.
