- Page 1 TVAC100013 User manual Version 06/2018 Original English user manual. Keep for future use.
- Page 2 The ABUS Security-Center GmbH assumes no liability for technical and typographical faults and reserves the right to make at any time modifications to the product or user manual without a previous announcement.
- Page 3 The warranty will expire for damage due to non-compliance with these operating instructions. ABUS will not be liable for any consequential loss! ABUS will not accept liability for damage to property or personal injury caused by incorrect handling or non-compliance with the safety-instructions.
- Page 4 Warnings Follow all safety and operating advises before starting-up the device! 1. Follow these directions in order to avoid damage of the power cord or plug: Do not modify or process the power cord or plug arbitrarily. Do not bend or twist the power cord. ...
-
Page 5: Table Of Contents
Table of contents Intended use ..........................6 Scope of delivery ........................6 Features and functions ......................6 Physical descriptions ........................ 7 Mounting ............................8 5.1 Power supply ..........................8 5.2 Ventilation ..........................8 5.3 Wall Mount ..........................8 Button description ........................9 Selecting the input signal ....................... -
Page 6: Intended Use
The 19,5” LED monitor displays FHD (1920x1080p) pictures in 16:9 formats. Thanks to its different connections, it can be connected flexibly to ABUS DVR, NVR,computers and directly to surveillance camera at the same time. Integrated loudspeaker and audio inputs also allow soundtracks to be played. -
Page 7: Physical Descriptions
4. Physical descriptions Power supply DC 12V / 3 A, Only use the power supply unit provided for operating the monitor! Audio in BNC Audio input 3.5mm , linked with BNC inputs Audio in PC Audio input 3.5mm , linked with VGA input BNC out (AHD/TVI/CVI) BNC Video out, parallel out of AHD/TVI/CVI input signal BNC in (AHD/TVI/CVI) -
Page 8: Mounting
For mounting the monitor at a wall please use a VESA compatible wall mount. At the backside of the monitor there are squarely arranged assembly holes (Middle distance 100 mm). These are compatible with the ABUS TVAC10500 wall mount. Please also pay attention to the installation manual of the wall mount. -
Page 9: Button Description
6. Button description Button Description Select one of the different input signals: VGA HDMI AHD/TVI/CVI SOURCE CVBS Open/Choice in the OSD menu Show the OSD (on-screen display) MENU Back/End a menu in the OSD ... -
Page 10: Selecting The Input Signal
7. Selecting the input signal To select the input signal, press the SOURCE button. The selected input will be displayed on the upper right of the screen. Press the SOURCE button repeatedly until you reach the required input and confirm with ► or ◄ button. -
Page 11: Picture / Color
8.1 Picture / Color To make settings for the picture display, press the MENU button and then press the SOURCE button to select the first menu item. The selected menu item is shown by a frame. The sub-menu item is highlighted. You can navigate between sub-menu items using the ◄►... -
Page 12: Function
8.4 Function Menu item Description OSD Language Setup Language of the OSD Restore user default Reset device to factory default settings No signal screen Adjust screen in case of “no signal” => blue or black No signal standby Adjust action in case of “no signal” => static on or automatic off Burn-in It is recommended to let this function enabled... -
Page 13: Maintenance And Cleaning
9. Maintenance and cleaning 9.1 Maintenance Regularly check the product's physical state, e.g. check for damage of the housing. If you suspect that safe operation cannot be guaranteed anymore, disconnect the product and ensure that it cannot be used by mistake. Remove the batteries. You can assume that safe operation is not possible anymore when ...
