AS18X/AS28X / en master / A31008-M2001-B101-1-19 / Overview.fm / 19.01.2011
Mitel 5505H handset
1 Charge status of
the batteries
2 Display keys
3 Message key
Flashes: new messages
received
4 Handsfree key
5 Control key (u)
6 Talk key
7 Directory key
(press down)
8 End call and
On/Off key
9 Ringer on/off
(press and hold
in idle status)
10 Keypad lock on/off
(press and hold)
11 Recall key
- Consultation call
(flash)
- Dialling pause
(press and hold)
12 Microphone
13 "Microphone off" key
ECO DECT
You are helping to protect the environment with your Mitel 5505H.
Reduced energy consumption
Your telephone has a power-saving adapter plug and uses less power.
Reduced transmission power (depending on the base station)
The transmission power can only be reduced if your base station supports this function.
The transmission power of your telephone is reduced automatically:
◆
The handset's transmission power is reduced depending on the distance to the base station.
◆
The transmission power on the base station is reduced to virtually zero when only one handset is regis-
tered and the handset is in the base station.
You can reduce the transmission power of the handset and base station even more by using Eco Mode/Eco
Mode+. For further information, please see your phone's user guide.
1
1
V
11.12.
11:56
INT
MENU
2
3
d
4
5
h
6
7
8
9
10
11
12
13
Display keys on handset:
Pressing a key launches the function that
appears above that key in the display.
Display
Function when pressed
icon
¢
INT
Call other registered handsets
page 7.
¢
MENU
Open main/submenu (see
Menu tree
"
Go back one menu level.
U
Scroll up/down or adjust
volume with u.
T
Move cursor to left/right
with u.
˜
Backspace deletes one charac-
ter at a time from right to left.
OK
Confirm menu function or save
entry.
page 16).
